Access control door unit Resist

Overview
RESIST-SA is a stand-alone access control device that stores codes and proximity cards, controls door opening and monitors door status (open/closed). It triggers an audible alarm on unauthorised openings. The unit operates fully autonomously (SA = Stand Alone) without an external management board or PC for programming and data storage.

Electronic assembly

• The electronic control system comprises two interconnected boards.
• CPU board: contains terminals, buzzer, relays and the interface for the passive proximity reader.
• Keypad board: contains push-buttons, LED indicators and the antenna for the passive proximity reader.

Compatibility
RESIST-SA functions as reader A (master) and can be connected to a standard RESIST unit acting as reader B (slave).

Variants
Model Variant | Part Number
Resist TPS SA | 403139
Resist T | 403124
Resist PS | 403125
Resist TPS | 403126

Technical specifications

• Stand-alone access control device (SA = Stand Alone).
• Stores user codes and proximity cards.
• Controls door opening and monitors open/closed status.
• Audible alarm on unauthorised opening.
• Two-board architecture: CPU board and keypad board.
• CPU board includes terminals, buzzer, relays and passive reader interface.
• Keypad board includes push-buttons, LED indicators and antenna for passive proximity reader.
• RESIST-SA acts as reader A (master) and can connect to a standard RESIST reader B (slave).
