Position indicator OP10

analoghollow-shaft

• Two counters with 5-digit (standard red digit indicates decimals; on request 2 red digits for hundredths or 5 black digits for mm). Reading until 99999. Digit height: 5,5 mm. • Shock-proof, self-extinguishing technopolymer case. Protection IP54. Temperature max.: 70°C. • Reading with 62° inclination. • Standard shaft hole: ø20 H7. Smaller bores with reducing bush (see p. 31). • Rotation direction of counters: clockwise-clockwise = DX-DX; anti-clockwise-anti-clockwise = SX-SX; clockwise-anti-clockwise = DX referred to the counter ① (upper); anti-clockwise-clockwise = SX referred to the counter ① (upper). • Version with 4-digits: “AZZ” with 1 positioning button for zero-set, version “2AZZ” with 2 positioning buttons for zero-set. • Colours: orange RAL 2004, black RAL 9005. ➜ Available only as spare parts, indicating the code and / or complete description (subject to availability).
