Sensor receiver MPAR series
Add to favorites
Compare this product
Characteristics
- Applications
- for sensors
Description
Product Description
These receivers are installed in the sub-plate or machine table to receive the locator units. Universal bolt-in receivers are interchangeable with competitive ball locking systems. They allow you to take advantage of the speed, precision and easy installation of the SpeedLoc System without the need to produce new sub-plates or reworking existing sub-plates. Mounting socket head cap screws are included. 180,000 psi tensile strength minimum. 140,000 psi yield strength minimum. Made from heat-treated 4340 steel with a black oxide finish.
Parts Table
Detail | ID | SKU | Part Number | Fixture Plate Thickness Min in | Locator Size | Thread Tap in | D Receiver Head Dia. in | D1 Fixture Plate Bore Dia. in | D2 Receiver OD in | D3 Fixture Plate Clearance Hole in | Dp Bolt Center Dia. in | H Receiver Height in | H1 Receiver Head Height in | H2 Fixture Plate C'Bore Depth in | SHCS Size | Screw Torque Max. ft/lbs | PN
129115 | MPAR-13001 | MPAR-13001 | .75 | 13 | 1/4-20 | 1.3748 | 1.3756 | .563 | .688 | .984 | .720 | .454 | .474 | #8-32 x .50 | 3.6 |
129119 | MPAR-16001 | MPAR-16001 | .75 | 16 | 5/16-18 | 1.4368 | 1.4376 | .688 | .813 | 1.125 | .720 | .454 | .474 | #8-32 x .50 | 3.6 |
129123 | MPAR-20001 | MPAR-20001 | 1.00 | 20 | 3/8-16 | 1.6871 | 1.6879 | .750 | .813 | 1.362 | .840 | .625 | .642 | #10-32 x .75 | 5.6 |
129127 | MPAR-25001 | MPAR-25001 | 1.25 | 25 | 1/2-13 | 2.0621 | 2.0629 | .875 | 1.000 | 1.644 | .955 | .785 | .804 | 1/4-28 x .88 | 14.4 |
129131 | MPAR-30001 | MPAR-30001 | 1.38 | 30 | 5/8-11 | 2.2652 | 2.2660 | 1.063 | 1.188 | 1.875 | 1.200 | .860 | .876 | 1/4-28 x 1.00 | 14.4 |
129135 | MPAR-35001 | MPAR-35001 | 1.50 | 35 | 3/4-10 | 2.6871 | 2.6879 | 1.438 | 1.563 | 2.178 | 1.265 | .890 | .909 | 5/16-24 x 1.00 | 28.8 |
129139 | MPAR-50001 | MPAR-50001 | 2.00 | 50 | 1-8 | 3.4996 | 3.5004 | 2.000 | 2.156 | 2.916 | 1.700 | 1.225 | 1.244 | 3/8-24 x 1.25 | 52.8 |
Media
Characteristics / Technical Specifications
These receivers are installed in the sub-plate or machine table to receive the locator units. Universal bolt-in receivers are interchangeable with competitive ball locking systems. They allow you to take advantage of the speed, precision and easy installation of the SpeedLoc System without the need to produce new sub-plates or reworking existing sub-plates. Mounting socket head cap screws are included. 180,000 psi tensile strength minimum. 140,000 psi yield strength minimum. Made from heat-treated 4340 steel with a black oxide finish.
Parts Table
Detail | ID | SKU | Part Number | Fixture Plate Thickness Min in | Locator Size | Thread Tap in | D Receiver Head Dia. in | D1 Fixture Plate Bore Dia. in | D2 Receiver OD in | D3 Fixture Plate Clearance Hole in | Dp Bolt Center Dia. in | H Receiver Height in | H1 Receiver Head Height in | H2 Fixture Plate C'Bore Depth in | SHCS Size | Screw Torque Max. ft/lbs | PN
129115 | MPAR-13001 | MPAR-13001 | .75 | 13 | 1/4-20 | 1.3748 | 1.3756 | .563 | .688 | .984 | .720 | .454 | .474 | #8-32 x .50 | 3.6 |
129119 | MPAR-16001 | MPAR-16001 | .75 | 16 | 5/16-18 | 1.4368 | 1.4376 | .688 | .813 | 1.125 | .720 | .454 | .474 | #8-32 x .50 | 3.6 |
129123 | MPAR-20001 | MPAR-20001 | 1.00 | 20 | 3/8-16 | 1.6871 | 1.6879 | .750 | .813 | 1.362 | .840 | .625 | .642 | #10-32 x .75 | 5.6 |
129127 | MPAR-25001 | MPAR-25001 | 1.25 | 25 | 1/2-13 | 2.0621 | 2.0629 | .875 | 1.000 | 1.644 | .955 | .785 | .804 | 1/4-28 x .88 | 14.4 |
129131 | MPAR-30001 | MPAR-30001 | 1.38 | 30 | 5/8-11 | 2.2652 | 2.2660 | 1.063 | 1.188 | 1.875 | 1.200 | .860 | .876 | 1/4-28 x 1.00 | 14.4 |
129135 | MPAR-35001 | MPAR-35001 | 1.50 | 35 | 3/4-10 | 2.6871 | 2.6879 | 1.438 | 1.563 | 2.178 | 1.265 | .890 | .909 | 5/16-24 x 1.00 | 28.8 |
129139 | MPAR-50001 | MPAR-50001 | 2.00 | 50 | 1-8 | 3.4996 | 3.5004 | 2.000 | 2.156 | 2.916 | 1.700 | 1.225 | 1.244 | 3/8-24 x 1.25 | 52.8 |
Media
- SpeedLoc Information (PDF)
Characteristics / Technical Specifications
- Mounting socket head cap screws included
- 180,000 psi tensile strength minimum
- 140,000 psi yield strength minimum
- Material: heat-treated 4340 steel
- Finish: black oxide
- Universal bolt-in receivers, interchangeable with competitive ball locking systems
- Intended for installation in sub-plate or machine table to receive locator units
