3-axis machining center FMC UNO

verticalfor steelfor aluminum

Overview
The FMC SERIE UNO is a compact 3‑axis machining centre with a pneumatic rotating work table (0°/90°/180°) designed for drilling and milling aluminium and steel profiles. It is supplied with standard minimum lubrication, double stops, a manual 6‑position tool magazine and a spindle with quick‑release tool coupling. The machine integrates bed, heads, vices and stops for production readiness.

Applications
Suitable for drilling, milling and secondary machining operations on extruded aluminium and steel profiles in small to medium production runs. Table rotation and tooling make it adaptable to multi‑face machining tasks.

Key features

• 3 controlled axes machining centre
• Pneumatic work table rotation: 0° / 90° / 180° (intermediate angles optional)
• Designed for aluminium and steel profile processing
• Minimum lubrication (MQL) as standard
• Double stop system (standard)
• Manual 6‑position tool magazine (standard)
• Spindle with quick‑release tool coupling
• Electrospindle up to 17,000 rpm
• Integrated machine bed, heads, vices and stops
• Operator interface: 21.5" screen

Options

• Automatic tool changer (optional)
• Rigid tapping (optional)
• Adjustable table rotation to intermediate angles (optional)
• Lubri‑cooling / coolant systems (optional)

Integrated software

• FSTCam4: integrated CAM package for processing extruded aluminium elements — manages design, job setup, work lists and execution in a single application; includes advanced machining strategies to optimise cycles and ensure part quality.

Documentation

• Product data sheet (FMC‑120)
• Brochure (FMC SERIE UNO)

Technical specifications

• Axes: 3 controlled axes
• Work table rotation: pneumatic 0° / 90° / 180° (intermediate angles optional)
• Spindle: quick‑release coupling; electrospindle up to 17,000 rpm
• Tool magazine: manual 6‑position (standard); automatic tool change optional
• Lubrication: minimum lubrication standard; lubri‑cooling optional
• Stops: double stop standard
• Operator interface: 21.5" screen
• Integrated CAM: FSTCam4
