Electronic thermostat Minibox-2M02

PTCprogrammablerelay

Overview
The Minibox-2M02 electronic thermostat is an ultra-compact digital controller designed to offer optimal precision in demanding chemical environments. Its front polyethylene membrane makes it resistant to harsh conditions, while its intuitive interface ensures quick and efficient use.

Technical Specifications

• Supply voltage: 230V single-phase (50/60 Hz).
• Maximum power: 2760 W at 230V.
• Output contact: 1 changeover contact (max. 12 A, 250V~).
• Measurement range: -80°C to +400°C (with 2-wire PT100 probe).
• Accuracy: ±1K ±0.5% of full scale.
• Inputs: PTC, PT100 2-wire or PT1000 2-wire.
• Output: to heating system via M16x1.5 cable gland.
• Protection rating: IP64 to EN 60529.
• Dimensions: 106 x 68 x 41 mm.
• Ambient temperature: 0…55°C; Storage temperature: -20…+70°C.
• Connection: Screw terminals for cables up to 2.5 mm².

Key Benefits

• Robust design: polyethylene membrane for chemical environments.
• Ease of use: direct access to settings via front panel interface and dedicated start/stop button.
• Integrated safety: probe monitoring (break or short-circuit) and key lock to protect the process.
• High precision: degree-accurate control thanks to clear 7-segment digital display.
• Easy mounting: wall-mounting with 4 slots at the rear.

Main Applications

• Thermal control for industrial heating systems.
• Use in harsh chemical environments.
• Precise temperature control in processes requiring reliable regulation.
• Applications in the pharmaceutical, chemical and food sectors.

Safety and Compliance

• Complies with EN 60529 (IP64 protection).
• Integrated protection against temperature sensor breakage and short-circuit.
• Proven resistance to harsh industrial conditions.

Caractéristiques / Spécifications techniques

• Supply voltage: 230V single-phase (50/60 Hz)
• Maximum power: 2760 W at 230V
• Output contact: 1 changeover contact (max. 12 A, 250V~)
• Measurement range: -80°C to +400°C (with 2-wire PT100 probe)
• Accuracy: ±1K ±0.5% of full scale
• Inputs: PTC, PT100 2-wire or PT1000 2-wire
• Output via M16x1.5 cable gland
• Protection rating: IP64 (EN 60529)
• Dimensions: 106 x 68 x 41 mm
• Ambient temperature: 0…55°C; Storage: -20…+70°C
• Connection: Screw terminals for cables up to 2.5 mm²
