Fuel hose Fuel Master™

PVCsmooth

Product Overview
Soft gray PVC sleeve designed to fit Gates Vapor Recovery Hose and provide a smooth banding surface for hose assemblies. Available as 100 ft hose-length variants and shorter sleeve lengths for repair or assembly.

All Parts / Variants (summary)

• 1-1/2X100 FUEL PVC VAP REC 5SD | Product #: 77447015 | ID: 1.5 in (38.1 mm) | OD: 1.88 in (47.8 mm) | Length: 100 ft | Max WP: 5 psi (0.3 bar)
• 2X100 FUEL PVC VAPOR REC 5SD | Product #: 77447020 | ID: 2.0 in (50.8 mm) | OD: 2.43 in (61.7 mm) | Length: 100 ft | Max WP: 5 psi (0.3 bar)
• 3X100 FUEL PVC VAP REC 5SD | Product #: 77447030 | ID: 3.0 in (76.2 mm) | OD: 3.54 in (89.9 mm) | Length: 100 ft | Max WP: 5 psi (0.3 bar)
• 4X100 FUEL PVC VAP REC 5SD | Product #: 77447040 | ID: 4.0 in (101.6 mm) | OD: 4.56 in (115.8 mm) | Length: 100 ft | Max WP: 5 psi (0.3 bar)
• 5X100 FUEL PVC VAP REC 5SD | Product #: 77447050 | ID: 5.0 in (127.0 mm) | OD: 5.51 in (140.0 mm) | Length: 100 ft | Max WP: 5 psi (0.3 bar)
• 6X100 FUEL PVC VAP REC 5SD | Product #: 77447060 | ID: 6.0 in (152.4 mm) | OD: 6.52 in (165.6 mm) | Length: 100 ft | Max WP: 5 psi (0.3 bar)
• 3X3FT FUEL MASTER PVC VAPOR RECOVERY 5SD SLEEVE | Product #: 77448030 | ID: 3.0 in (76.2 mm) | OD: not specified | Length: 3 ft | Max WP: not specified
• 4X3FT FUEL MASTER PVC VAPOR RECOVERY 5SD SLEEVE | Product #: 77448040 | ID: 4.0 in (101.6 mm) | OD: not specified | Length: 3 ft | Max WP: not specified

Usage & Notes

• Designed to slide over Gates Vapor Recovery Hose to protect and present a smooth banding surface for clamps and fittings.
• 100 ft variants are supplied as sleeve over hose assemblies; 3 ft variants are supplied as shorter sleeves for repairs or custom assemblies.
• Maximum working pressure for the 100 ft hose variants: 5 psi (0.3 bar).
• Check part numbers to match required inside diameter and sleeve length for installation.

Technical specifications

• Material: Soft gray PVC (sleeve).
• Function: Vapor recovery hose sleeve — protects hose and provides smooth banding surface for assemblies and clamps.
• Available product numbers / variants: 77447015, 77447020, 77447030, 77447040, 77447050, 77447060, 77448030, 77448040.
• Available inside diameters (in/mm): 1.5 in (38.1 mm), 2.0 in (50.8 mm), 3.0 in (76.2 mm), 4.0 in (101.6 mm), 5.0 in (127.0 mm), 6.0 in (152.4 mm).
• Outside diameters (in/mm) for 100 ft variants: 1.88 in (47.8 mm), 2.43 in (61.7 mm), 3.54 in (89.9 mm), 4.56 in (115.8 mm), 5.51 in (140.0 mm), 6.52 in (165.6 mm).
• Typical lengths: 100 ft for hose-length variants; 3 ft for sleeve variants.
