Direct-operated solenoid valve P7129
2-wayNCNO

Direct-operated solenoid valve - P7129 - GEVASOL - 2-way / NC / NO
Direct-operated solenoid valve - P7129 - GEVASOL - 2-way / NC / NO
Direct-operated solenoid valve - P7129 - GEVASOL - 2-way / NC / NO - image - 2
Direct-operated solenoid valve - P7129 - GEVASOL - 2-way / NC / NO - image - 3
Add to favorites
Compare this product
Go to the GEVASOL website for more information

Characteristics

Control
direct-operated
Ports/positions
2-way
Function
NC, NO
Medium
for natural gas
Body
with sub-base, IP65, stainless steel, brass
Other characteristics
high-pressure, high-speed
DN

Max.: 2 mm
(0.079 in)

Min.: 1 mm
(0.039 in)

Voltage

24 V

Temperature

Max.: 80 °C
(176 °F)

Min.: -10 °C
(14 °F)

Pressure

Max.: 160 bar
(2,320.6 psi)

Min.: 0 bar
(0 psi)

Description

Low leak, high speed and precision solenoid. Instrumentation Specifications Pitch [mm] 32 Seal PU, EPDM Type of acting On / Off Material in contact with media - Base Brass or AISI316 Material in contact with media - Seals PU, EPDM Temperature range - Storage [°C] -15 - +70 Temperature range - Ambient [°C] -15 - 55 Temperature range - Media [°C] -10 - +80 (nonfreezing) Flow factor kv [l/min] 0.7 Nominal consumption power [W] 14 Duty cycle 100% - with power saving | 70% without power saving Electrical connection [mm] DIN43650 Type A
