Gas igniter GS6

This economical ignition module is designed for engines from 1 to 6 cylinders - up to 800 in3 (13 L) total displacement which will benefit from the latest in inductive ignition technology. Inductive technology allows for adjustable continuous spark duration - up to 1,500 microseconds on rich-burn, lean-burn, naturally aspirated or turbocharged versions. Fuel types such as natural gas, propane, LPG, landfill, digester and other biogas fuels are also compatible. Programme adjustments to optimise engine performance are easy with the Windows® based software. The GS 6 is available in different options allowing for inductive and/or Hall Effect pickup sensors for timing input, which can be the Gill timing disc and standard pickup, existing OEM cam disc, A5 conversion kit or a drilled flywheel pattern for wasted spark firing. Up to 1,500 microseconds of continuous spark duration Single or Dual Pickup Timing Input Easy to use Windows® based software TECHNICAL Number of cylinders: 1-6 Power: 12 / 24 VDC. 5 Amp Spark Energy / Duration: 500 to 1,500 µSeconds Timing: Global, Dual Fuel Timing Maps: 2D - speed and timing, 2 maps Trigger Methods: Inductive/ Hall Effect Pickup Visual Features: On-board LED status light Application: Engines less than 800 inches cubed (13 L) Software: Windows® based Gillfire Environmental: Sealed to IP 67 Standards
