Position indicator VI 7

universalLCDwith LED display

Compact-design, modern and functional digital readout. Diagnostic of readout and optical scales. Resolutions up to 0.5 μm. Reading of coded references. Universal software for any kind of machine tool. Software upgrade through serial port. 1,000 memory blocks. Option: flush-mounted version (on a panel). Easy and immediate use of several dedicated functions. MAIN FUNCTIONS SELF-TESTING DEVICE DIAGNOSTIC INVERSION OF COUNTING DIRECTION ABSOLUTE/INCREMENTAL COUNTING MM/INCH CONVERSION RADIUS/DIAMETER CONVERSION VARIABLE RESOLUTION SCALE ZERO REFERENCE (REF) MEMORY CLEARING POSITION RESET/PRESET ANGULAR READING SEXAGESIMAL DEGREES READING CALCULATOR AXIS COUPLING W AXIS DISPLAYING SPECIAL FUNCTIONS RECALL 100 TOOL OFFSETS 100 ORIGINS OF THE AXES ZERO APPROACHING ALERT SETTING THE TYPE OF SPINDLE ROTATION SPEED CONSTANT PITCH INCLINED CONSTANT PITCH LINEAR CORRECTION NON-LINEAR CORRECTION SCALE FACTOR CIRCUMFERENCE CENTER MIDPOINT CALCULATION MIRROR IMAGE ROUND FLANGE SPECIAL ROUND FLANGE PROGRAMMING THE MEMORY BLOCKS SERIAL OUTPUT RS-232 SETTING PRINTING LINE SPACINGS ENABLING THE AUTOMATIC TRANSMISSION OF POSITIONS BUZZER ON/OFF FUNCTIONS LCD VERSION (VI 700 L) LANGUAGE SELECTION TAPER CALCULATION AUTOMATIC TAPER CALCULATION THREADS CALCULATION MATERIAL WEIGHT CALCULATION PERIPHERAL SPEED CALCULATION ANGULAR SPEED CALCULATION SCALE FACTOR DISPLAYING AXES SPEED DISPLAYING RECALLED ORIGINS/TOOLS DISPLAYING
