Thermocouple kit TW158

Description
A compact, lightweight, hand-held unit powered by four 1.5V AA batteries. Uses a capacitance-discharge method to attach a thermocouple wire to a workpiece, enabling temperature-recording and control instruments to obtain accurate temperature readings during heat treatment operations.

Applications

• Variable, operator-selectable energy output from 20 to 50 Joules, suitable for attaching a range of thermocouple wire sizes.
• Selectable manual or automatic operating modes; suitable for attaching thermocouples in confined or hard-to-reach areas and where the operator must keep a hand free for safety.

Technical specifications

• Model: TW158
• Product code: GHT4004
• SKU: ght4004
• Power source: Four × 1.5V AA batteries
• Attachment method: Capacitance-discharge
• Energy output: Variable, operator selectable 20–50 Joules
• Operating modes: Manual or automatic
• Suitable for: Attaching various sizes of thermocouple wire
• Variants available: 110V, 240V (product variant options)
• Portability: Compact, lightweight, hand-held unit
