Thermocouple kit GTW-V50

Overview
The GTW-V50 is a portable, battery-powered thermocouple attachment unit that uses a capacitance-discharge method to spot-weld thermocouple wire to workpieces for temperature measurement during heat treatment. The unit provides operator-selectable energy and both automatic and manual modes for controlled, repeatable welds.

Applications
Designed for field and workshop use, the GTW-V50 is suitable for attaching solid thermocouple wire in hard-to-reach locations and on components where the operator may require a free hand for safety. Typical applications include heat treatment monitoring, metallurgical testing and production temperature checks.

Features

• Operator-selectable energy: 22–50 J
• Automatic and Manual operation
• Automatic mode: stripped-back TC wire held in pliers with magnet providing welding return; unit senses contact and performs automatic spot weld, then recharges
• Manual mode: TC wire held in pliers against the workpiece with magnet return; pressing 'Weld' initiates spot weld
• Compatible with solid thermocouple wire 0.5 mm–1.7 mm
• Rechargeable battery with low-battery LED indicator
• Auto switch-off after 3 minutes to conserve battery
• Maximum output voltage: 60 V
• Stainless-steel enclosure with shoulder strap and tool storage
• Supplied with pliers, welding return magnet and supply lead
• Available voltage variants: 110 V or 240 V

Technical specifications

• Model: GTW-V50
• Product code: GHT4100
• SKU: ght4100
• Energy output: 22 – 50 Joules (variable, operator selectable)
• Thermocouple wire size: 0.5 mm to 1.7 mm (solid wire)
• Operation modes: Automatic and Manual
• Power: Rechargeable battery
• Low battery indicator: LED
• Auto switch-off: after 3 minutes
• Maximum output voltage: 60 V
• Enclosure: Stainless-steel case with shoulder strap and tool storage
• Included accessories: set of pliers, welding return magnet, supply and supply lead
• Available voltage variants: 110 V or 240 V
