Crimping press P107 BTmotorizedautomaticvertical
Add to favorites
Compare this product
Characteristics
- Operation
- motorized
- Function
- crimping
- Control
- automatic
- Other characteristics
- vertical
- Force
20,000 N
- Stroke
40 mm
(2 in)- Weight
60 kg
(132 lb)- Overall length
290 mm
(11 in)- Overall width
260 mm
(10 in)- Overall height
630 mm
(25 in)
Description
The CRIMPING PRESS P107 BT was made specifically to CRIMP WIRES through the use of miniapplicators.
The particular inductive braking system has allowed to realize a CRIMP CABLES extremely silent also solving the problem of maintenance and replacement of the electromechanical brakes on traditional brake motors.
The cooling system of the CRIMPING PRESS P107 BT with solenoid valve and the dimension compact make seam particularly suitable to be used on automatic machines.
The CRIMPING PRESS P107 BT comes complete with guards and safety devices, supports reel, instruction manual and keys supplied.
ALIMENTATION - Triphase 380 V 50/60 Hz
PNEUMATIC ALIMENTATION - No
WORKABLE SECTIONS - Till to 6 mm²
WORKABLE TERMINALS - Whatever
PRODUCTIVITY - 2.000÷3.000 pcs/h
DISPLAY - Digital Numerical Display
