Coil unwinder 600S

cablehankmotorized

The PREFEEDER GM UNROAL 600S allows you to unwind cables automatically by storing them from hanks and reels up to 1000 mm in diameter and up to a maximum of 600kg. The PREFEEDER GM UNROAL 600S is equipped with a motorized lifting shaft to facilitate the loading of the reel by the operator and without damaging the reel itself. Equipped with automatic Start / Stop with automatic speed adjustment of the machine to which it is connected. The lung allows a correct unwinding of the cable for a correct subsequent processing. The PREFEEDER GM UNROAL 600S is equipped with user manuals and CE certification. ALIMENTATION - Monophase 230 V 50/60 Hz PNEUMATIC ALIMENTATION - No ABSORBMENT - 400 W MAX COIL WEIGHT - 400 Kg FEEDING - 1 Drive Roller WORKABLE CABLE - PVC-Teflon-Silicon-Glass PRODUCTIVITY - Depends MAX CABLE DIAMENTER - Customizable DISPLAY - No MEMORY - No WEIGHT - 160 Kg DIMENSIONS - 1400x600x880 mm (WxDxH)
