Manual unwinder GM121

cablecoil

The MANUAL HORIZONTAL PREFEEDER GM121, designed as a support for CUTTING AND STRIPPING MACHINES or CUTTING MACHINES, in addition to avoiding excessive stress on these machines, is used to keep the CABLE in constant tension and thus guarantee greater cutting precision. This is made possible thanks to the adjustable force tensioning arm which, when connected to the COIL brake, keeps the material's traction constant. The support disk of the COIL is mounted on a thrust ball bearing. The MANUAL HORIZONTAL PREFEEDER GM121 must be, at the customer's choice, equipped with a 160 or 250 centering device (see characteristics shown in the table). ALIMENTATION - No PNEUMATIC ALIMENTATION - No ABSORBMENT - No MAX COIL DIAMETER - 500 mm MAX COIL WIDTH - Depends MAX COIL WEIGHT - 28 Kg FEEDING - No WORKABLE CABLE - PVC-Teflon-Silicon-Glass PRODUCTIVITY - Depends CENTRAL PIN DIAMETER - 15 mm (Without Centering Device) (Customizable) CENTERING DEVICE 160 - Adjustable from 70 to 160 mm - H Pin 180 mm CENTERING DEVICE 250 - Adjustable from 100 to 250 mm - H Pin 180 mm DISPLAY - No MEMORY - No WEIGHT - 8 Kg DIMENSIONS - 600x380x500 mm (WxDxH)
