Molding press MELT 2T

manualpneumaticfor plastics

The DIE CASTING MOLDING PRESS SYSTEM GM MELT 2T is a two-head horizontal injection co-molding machine for the production of ergonomic mono-component resin co-molds (melt) with automatic control programmable by PLC. It allows you to print connectors and plugs of plastic material in order to achieve the processing required by the customer through the custom-made molds The DIE CASTING MOLDING PRESS SYSTEM GM MELT 2T has an aluminum profile structure complete with 4 liter melter, 2 high viscosity gun and 2 high temperature pipes with pneumatically or manually operated descent and closure of the mold on 4-column guides with descent in safety in manual mode for mold mounting and centering, injector advancement stroke on adjustable slides. The DIE CASTING MOLDING PRESS SYSTEM GM MELT 2T has a PLC production cycle process control with the possibility of programming up to 100 recipes that can be memorized for the times of first and second injection, maintenance, air and water cooling. The DIE CASTING MOLDING PRESS SYSTEM GM MELT 2T has a melter with temperature control on three zones (melting - tube - injection head) with provision for co-molded expulsion. FUSOR ALIMENTATION - Triphase 380 V 50/60 Hz COMMAND CONSOLE ALIMENTATION - Monophase 230 V 50/60 Hz FUSOR ABSORMENT - 4.400 W CYCLE TIME - Programmable CLOSING AND OPENING OF THE MOLD HOLDER - Manual MOLD DIMENSIONS - Customizable WORKABLE DIAMETERS - On Customer Request PRODUCTIVITY - Depends DISPLAY - Touch Screen LCD Liquid Cristal Display MEMORY - 100
