Biconical mixer MBHrotary drumhorizontalcontinuous
Add to favorites
Compare this product
Characteristics
- Technology
- rotary drum
- Configuration
- horizontal
- Batch/continuous
- batch, continuous
- Product type
- solid/liquid, powder, granules
- Applications
- for the chemical industry, for bulk materials, for the recycling industry
- Other characteristics
- steel, rotary, biconical
- Engine power
Max.: 110 kW
(149.56 hp)Min.: 4 kW
(5.44 hp)- Capacity
Max.: 1,500 l
(396.26 gal)Min.: 50 l
(13.21 gal)- Empty weight
Max.: 27,500 kg
(60,627.1 lb)Min.: 1,500 kg
(3,306.9 lb)
Description
THEORY OF OPERATION:
- This is a rotary mixer with mixing provided in the bowl by an inverted spiral system; emplying is by reversing the direction of rotation.
- The equipment can be used for continuous service or discontinuous service.
- The extremely thorough mixture obtained is due to the discontinuous spirals and to the lifting and mixing shovels.
- Adaptation of a dusting attachment is obtained easily.
DESIGN:
- Fabrication material: carbon or stainless steel.
- The bowl consists of two truncated cones within wich are welded discontinuous spirals.
- Rotation is on four polyurethane-bound roller offering excellent resistance and drive by a reduction motor.
- For a product density greater than 2.5, all four rollers are motor-driven.
ADVANTAGES:
-Silent. Sealed.
-Maintenance reduced to greasing the bearing.
-No mechanical parts in contact with product.
-Flameproof.
