Vertical conveyor chainfor bottlescarton
Add to favorites
Compare this product
Characteristics
- Technology
- chain
- Form
- vertical
- Transported product
- for bottles, carton, glass
- Other characteristics
- automatic
- Maximum load
15 kg, 40 kg
(33.069 lb, 88.185 lb)
Description
The Gronemeyer vertical conveying system is used to overcome differences in height in product lines. The gripper technology permits space-saving vertical transport. Bottles, glasses, tins, cartons, bundles, etc. can be transported using this conveying principles.
Technical data:
-Chain width: 46 mm/114 mm/254 mm
-Conveying performance: up to 60,000 units/h
-Difference in height: up to 8m/12m/12m
-Product weight: up to 15kg/40kg/40kg
-Product width: 15 - 200 mm/20 - 450 mm/20 - 450 mm
-Solid steel construction in painted or stainless-steel version
-Manual width adjustment
-Automatic tensioning station for the cleated chain
-Central lubrication system for the cleated chain
