Mobile crane LTC250T5

telescopicall-terrainlifting

Overview
The LTC250T5 is a mobile all-terrain crane with a rated lifting capacity of 25 t and a maximum main boom length of 43 m. It combines long-reach capability with road mobility and outrigged working stability.

Key specifications

• Overall length: 12,945 mm
• Overall width: 2,550 mm
• Overall height: 3,465 mm
• Basic boom length: 10.9 m
• Max. main boom length: 43 m
• Max. rated lifting capacity: 25 t
• Total weight during driving: 33,430 kg
• Engine model / power: ISLe290 30 (Euro III) / 213 kW @ 2,100 rpm
• Max. travel speed: 80 km/h

Features

• Main boom with full extension to 43 m and enlarged section; full-extension lifting capacity up to 7.45 t
• 7-ton counterweight and 6.42 m outrigger transverse span for enhanced operational stability
• 2.55 m wide chassis with large rectangular-section frame increasing resistance to lifting, torsion and bending
• One-click start for boarding operations to simplify engine start-up
• High-intensity LED outrigger leg lighting with switch located in the driver’s cab for night work
• Frame-type aluminum alloy engine hood, pneumatic shock-absorbing seats and foldable sleeper; quick-change hook
• Liugong-integrated main valve hydraulic system with new pilot handle for improved operator control

Technical specifications

• Axle distance: 4,635 + 1,350 mm
• Wheel distances: 2,080 / 1,865 / 1,865 mm
• Min. turning diameter: 21 m
• Approach / departure angle: 11° / 14°
• Outrigger longitudinal span: 5.5 m
• Outrigger transversal span: 6.42 m
• Boom extension time (extend / retract): 98 / 108 s
• Boom luffing time (lifting / descending): 40 / 65 s
• Max. slewing speed: 2.4 r/min
• Max. lifting speed (main winch, no load): 120 m/min
• Max. lifting speed (auxiliary winch, no load): 120 m/min
• Max. rated power of the engine: 213 kW @ 2,100 rpm
• Max. rated torque of the engine: 1,050 N·m @ 1,000–1,900 rpm
• Dimensions (L x W x H): 12,945 x 2,550 x 3,465 mm
• Total weight during driving: 33,430 kg
