Sorting screener S14E
sand productionfor crusher loadingfor mining

Sorting screener - S14E - Guangxi Mesda Engineering Machinery Co., Ltd - sand production / for crusher loading / for mining
Sorting screener - S14E - Guangxi Mesda Engineering Machinery Co., Ltd - sand production / for crusher loading / for mining
Sorting screener - S14E - Guangxi Mesda Engineering Machinery Co., Ltd - sand production / for crusher loading / for mining - image - 2
Sorting screener - S14E - Guangxi Mesda Engineering Machinery Co., Ltd - sand production / for crusher loading / for mining - image - 3
Sorting screener - S14E - Guangxi Mesda Engineering Machinery Co., Ltd - sand production / for crusher loading / for mining - image - 4
Sorting screener - S14E - Guangxi Mesda Engineering Machinery Co., Ltd - sand production / for crusher loading / for mining - image - 5
Add to favorites
Compare this product

Characteristics

Applications
sorting, sand production, for crusher loading, for mining, for recycling, construction
Type
vibrating
Material
for bulk materials, for waste
Other characteristics
rectangular, 3-deck, high throughput, heavy-duty
Weight

36,000 kg
(79,366 lb)

Screening surface

14 m²
(150.7 ft²)

Capacity

Min.: 150 t/h
(92 lb/s)

Max.: 350 t/h
(214 lb/s)

Engine power

67 kW
(91.09 hp)

Description

Main features
Heavy-duty screen box design with reinforced structure. Three screening decks and large screening surface for high throughput and precise sizing. Modular layout for transport and on-site installation.

Applications
  • Quarrying and aggregates
  • Mining and mineral processing
  • Sand and gravel classification
  • Construction and demolition recycling


Technical parameters
  • Product model: S14E
  • Decks: 3
  • Screening surface (L×W, mm): 7000 × 2000
  • Screening power (kW): 28
  • Total power (kW): 67
  • Drive mode: Electric (option: diesel generator)
  • Processing capacity (t/h): 150–350
  • Overall weight (t): 36
  • Transport dimensions (L×W×H, mm): 15343 × 3603 × 3870


Optional equipment
  • Side discharge conveyors
  • Iron remover / magnetic separator
  • Dust suppression system
  • Diesel-electric generator (dual power)
  • PLC or remote control systems
  • Custom trommel (on request)


Notes
  • Processing capacity depends on material hardness, feed size and required product gradation.
  • Standard configuration: manual control. PLC/automatic control available as option.
  • Technical specifications are subject to change due to continuous product improvements; final parameters depend on the delivered unit.
