Simple mechanical structure.
Accessories complete
Generator included
Equipped with screening function
Powerful screening ability
Sturdy and durable
Easy to use
TECHNICAL PARAMETERS
PROJECT - NAME - PT-6018C - COMMENT
Hopper - Feeding capacity(t/h) - 350 -
Max feed size(mm) - 200 -
Feeding height (mm) - 2820 -
Length x Width(mm) - 10600 × B1000 -
Power (kw) - 11 -
Volume (m³) - 3 -
Vibrating screen - Length × width(mm) - 6000 × 1800 -
Power (KW) - 19 -
Desk - 3 -
A conveyor(1st desk) - Discharge height (mm) - 3260 -
Length x Width(mm) - 7250 × B500 -
Power (KW) - 4 -
B conveyor(2nd desk) - Discharge height (mm) - 3260 -
Length x Width(mm) - 7250 × B500 -
Power (KW) - 4 -
C conveyor(3rd desk) - Discharge height (mm) - 3000 -
Length x Width(mm) - 5720 × B500 -
Power (KW) - 4 -
D conveyor(bottom desk) - Discharge height (mm) - 3260 -
Length x Width(mm) - 6600 × B1000 -
Power (KW) - 7.5 -
Generator power (kw) - 100 -
Hydraulic station power(kw) - 55 -
Total power (KW) - 50 -
Output capacity(t/h) - 120-300 -
Work dimension(L x W x H/mm) - 13200 × 13300 × 5750 -
Description:
1. The parameter in brackets is the onboard generator scheme.
2. Crusher processing capacity is related to stone hardness, feed size, and discharge size.
3. Basic configuration:manual control 、wireless remote control、Automatic feeding system.
4. Options:side conveyor belt 、iron remover 、water spraying system.
