Bench-top torque meter QUANTEC MCS ®
for calibrationfor torque and angle measurementfor loosening torque

Bench-top torque meter - QUANTEC MCS ® - GWK Norbert Gerlach GmbH & Co. KG - for calibration / for torque and angle measurement / for loosening torque

Bench-top torque meter - QUANTEC MCS ® - GWK Norbert Gerlach GmbH & Co. KG - for calibration / for torque and angle measurement / for loosening torque - image - 2

Bench-top torque meter - QUANTEC MCS ® - GWK Norbert Gerlach GmbH & Co. KG - for calibration / for torque and angle measurement / for loosening torque - image - 3

Bench-top torque meter - QUANTEC MCS ® - GWK Norbert Gerlach GmbH & Co. KG - for calibration / for torque and angle measurement / for loosening torque - image - 4

Add to favorites

Compare this product

Go to the GWK Norbert Gerlach GmbH & Co. KG website for more information

Characteristics

Type

bench-top

Applications

for calibration, for torque and angle measurement, for loosening torque

Other characteristics

with graphic display, electronic, with external sensor

Torque

Max.: 1,000 Nm
(737.56 ft.lb)

Min.: 2 Nm
(1.48 ft.lb)

Description

Product overview
The electronic torque and angle measurement system for development, quality assurance and analysis. Designed as a compact screw laboratory for bench and laboratory use.

Performance characteristics

Torque measuring range: 2 - 1000 N·m
Operating modes: torque control and angle of rotation control
Yield point detection and control
Audit functions for torque and loosening-tightening cycles
Additional torque measurement channel for process capability investigations
PFU compliant with VDI / VDE 2645
Wireless data transmission via WLAN and ZIGBEE
Additional measuring channel for preload/pretension force sensors
Compatible with analysis software Ceus and QS-Torque
Intuitive graphical touch user interface

Highlights

Integrated touch display for test control and visualization
Extra measurement channel for pretension/preload sensors
Vibration alarm for process feedback
Technical data sheets available in German and English

Technical specifications

Measuring range: 2 - 1000 N·m
Control modes: torque control, angle control
Yield point detection
Audit functions: torque and loosening-tightening
PFU according to VDI / VDE 2645
Wireless: WLAN, ZIGBEE
Additional channel for preload force sensors
Software compatibility: Ceus, QS-Torque
Interface: graphical touch display

Recommended applications

Research and development of fastening systems
Quality assurance and incoming inspection
Process capability studies and audit tests
Laboratory measurements and calibration checks
Production sampling and assembly process validation

Connectivity and options

Wireless data export via WLAN and ZIGBEE
Support for external preload/pretension sensors
Data analysis and reporting with Ceus and QS-Torque
Available options: extended measuring channels, calibration certificates, custom fixtures
