Torque verification tool DWPM-1000

Overview
Fully automatic testing device for electronic torque/angle wrenches with gyroscopic angle measurement. Designed for calibration laboratories and production quality control. Model DWPM-1000 provides automated torque and rotation-angle verification with tool communication and database management.

Performance characteristics

• Test range: 2 - 1000 N·m and up to 360° rotation
• Torque accuracy class: 0.2
• Repeat accuracy (angle): 0.01°
• Acceptable tool length: 136 - 1590 mm
• Test programs compliant with DIN EN ISO 6789 and based on VDI/VDE 2648
• Swiveling table (90°) for gravity-effect examination
• Adjustable travel speed: 0 - 60 °/s
• Industrial PC with 19" touch panel
• Interface for tool communication and included database software

Technical specifications

• Torque range: 2 - 1000 N·m
• Rotation angle: up to 360°
• Accuracy class (torque): 0.2
• Repeat accuracy (angle): 0.01°
• Tool length range: 136 - 1590 mm
• Standards: DIN EN ISO 6789; based on VDI/VDE 2648
• Swiveling table: 90°
• Travel speed: 0 - 60 °/s
• Operating hardware: Industrial PC with 19" touch panel monitor
• Connectivity: Interface for tool communication
• Software: Database software included
