Servo-hydraulic press SSP4-3300motorizedformingblanking
Add to favorites
Compare this product
Characteristics
- Operation
- servo-hydraulic, motorized
- Function
- forming, blanking, tryout, embossing
- Structure
- ram, friction screw, double-spindle
- Control
- fully-automatic, PLC-controlled
- Other characteristics
- vertical, servo-driven, double-action, transfer, universal, continuous
- Applications
- for automotive parts, for production, for the automotive industry, process, for industrial applications, for battery pole, for sheet metal, laboratory, for automotive applications, for steel, for aluminum, for tools, for the aeronautical industry, expanded metal, for the aerospace industry
- Force
3,300 kN
- Opening
Max.: 1,900 mm
(75 in)1,200 mm
(47 in)Min.: 1,000 mm
(39 in)- Rate (strokes/min)
Max.: 150 p/min
100 p/min
Min.: 20 p/min
- Stroke
Max.: 350 mm
(14 in)200 mm
(8 in)Min.: 75 mm
(3 in)- Table width
Max.: 2,500 mm
(98 in)1,500 mm
(59 in)Min.: 80 mm
(3 in)
Description
Tryout and pilot production press with four servo-hydraulic die cushion systems for fine blanking, embossing and calibrations.
Tryout and pilot production press:
Blanking and forming parts for drive systems for passenger cars, commercial vehicles, boats, aviation and amusement rides
Servo hydraulic die cushion systems in bolster and ram
