Battery test machine HD-H206

impactsemi-automatic

Battery Crash Test Machine Trade term: CIF Lead time: Shipment for the above equipment is 25 working days upon receipt of down payment. Payment: T/T full payment in advance Validity: This quote is firm for 30 days - Warranty: One-year warranty on all parts, labor is not covered. TEST PURPOSE The battery pack is placed on the impact table and fixed in the fixture (the largest surface of the battery pack should be perpendicular to the table top). The weight of the 10kg weight is freely dropped from 1.0m. The battery pack is allowed to deform, and it should not ignite or explode. TEST STANDARD UL 1642:2012; UL 2054:2012; IEC 62281:2004 STANDARD FEATURES Weight of falling ball:9.1kg±0.46kg (20±1 lb) and 10kg Impact height:610~1000mm Height display:through the altimeter display, accurate ± 5mm Horizontal bar:15.8 ± 0.2mm (5 / 8 inch) steel rod Internal material:stainless steel plate External material:cold-rolled sheet paint treatment, thickness 1.5mm Exhaust air outlet:diameter 100mm Max. size of test battery:250 * 250 * 250mm Protection device:upper and lower limit protection switch, safety block, located at the bottom of the weight, play a protective role in the event of sudden power failure Viewing window:250mm * 250mm Machine dimension(L*W*H):700*800*1650mm Power supply:1-phase, 220V, 50Hz
