Single-shaft positioning system HDA 70

rotaryautomaticindustrial

Positioning system HIPERDRIVE HDA 70 with 42 W nominal power output Special features Bus interfaces simplify start-up and wiring complexity Durable EC-motor Status messages retrievable via bus With bevel gear (optional) The HIPERDRIVE HDA 70 allows adjustment procedures for positioning and auxiliary axes to be performed efficiently, at low cost and with a high degree of precision. The HIPERDRIVE is available with a Industrial Ethernet interface for direct connection to a control module and with RS 485 for connection to a Hub. Technical data Nominal torque / nominal rated speed 15 Nm / 27 min-1 Interface / bus communication EtherCAT, EtherNet/IP, PROFIBUS DP, PROFINET Positioning accuracy ± 1° Power supply 24 VDC, ± 15 % Output shaft 10 mm hollow shaft (only radial, with bevel gear) 12 mm hollow shaft (only radial, with bevel gear) 10 mm solid shaft with feather key (axial) 10 mm solid shaft with feather key (radial, with bevel gear) Positioning range 32,000 rotations, not subject to mechanical limits Protection class IP 65
