Oil filter KGY series

compressed airfiberglasscyclone

Product Overview
KGY compressed-air oil removal filters combine cyclone separation, pre-filtration and ultrafine glass-fiber coalescing stages to minimize oil carryover from oil-lubricated compressors. They are engineered for continuous industrial use where low downstream oil content and stable pressure are required.

Key Features

• Three-stage oil removal: cyclone separation, pre-filtration and coalescing fine filtration for effective oil separation.
• Ultrafine glass fiber media delivering very low outlet oil content (typically 0.1–0.01 ppm).
• Wide flow coverage: modular models from 1.6 to 510 Nm³/min to suit small to large compressed-air systems.
• Available with threaded (ZG) or flanged (DN) connections for straightforward installation.

Product Specifications

• Flow range: 1.6–510 Nm³/min
• Working pressure: 0.2–1.0 MPa
• Inlet temperature range: 5–65°C
• Outlet oil content after filtration: typically 0.1–0.01 ppm
• Initial pressure drop: 0.025 MPa

Models & Specifications (table)
Model | Rated Flow | Working Pressure | Connection | Height (mm) | Diameter (mm) | Weight (kg)
KGY-1N | 1.6 Nm³/min | 0.2–1.0 MPa | ZG1 | 740 | 159 | 55
KGY-2N | 2.6 Nm³/min | 0.2–1.0 MPa | ZG1 | 880 | 159 | 60
KGY-3N | 3.8 Nm³/min | 0.2–1.0 MPa | ZG1 | 993 | 159 | 85
KGY-6N | 7 Nm³/min | 0.2–1.0 MPa | ZG1-1/2 | 1300 | 159 | 100
KGY-8N | 8.5 Nm³/min | 0.2–1.0 MPa | ZG1-1/2 | 1530 | 159 | 110
KGY-10N | 11.5 Nm³/min | 0.2–1.0 MPa | ZG2 | 1600 | 159 | 115
KGY-12N | 13 Nm³/min | 0.2–1.0 MPa | ZG2 | 1700 | 219 | 120
KGY-15N | 17 Nm³/min | 0.2–1.0 MPa | DN65 | 1980 | 219 | 135
KGY-20N | 23 Nm³/min | 0.2–1.0 MPa | DN65 | 1625 | 325 | 155
KGY-25N | 27 Nm³/min | 0.2–1.0 MPa | DN80 | 1765 | 325 | 210
KGY-30N | 34 Nm³/min | 0.2–1.0 MPa | DN80 | 2110 | 325 | 215
KGY-40N | 45 Nm³/min | 0.2–1.0 MPa | DN100 | 2320 | 325 | 236
KGY-50N | 55 Nm³/min | 0.2–1.0 MPa | DN100 | 2050 | 377 | 270
KGY-60N | 65 Nm³/min | 0.2–1.0 MPa | DN125 | 2350 | 377 | 300
KGY-80N | 87 Nm³/min | 0.2–1.0 MPa | DN150 | 2350 | 377 | 315
KGY-100N | 110 Nm³/min | 0.2–1.0 MPa | DN150 | 2420 | 426 | 360
KGY-120N | 130 Nm³/min | 0.2–1.0 MPa | DN150 | 2422 | 426 | 400
KGY-150N | 160 Nm³/min | 0.2–1.0 MPa | DN200 | 2420 | 550 | 410
KGY-200N | 210 Nm³/min | 0.2–1.0 MPa | DN200 | 2334 | 550 | 470
KGY-250N | 260 Nm³/min | 0.2–1.0 MPa | DN250 | 2380 | 550 | 540
KGY-300N | 320 Nm³/min | 0.2–1.0 MPa | DN250 | 2380 | 550 | 550
KGY-350N | 360 Nm³/min | 0.2–1.0 MPa | DN300 | 2500 | 600 | 650
KGY-400N | 410 Nm³/min | 0.2–1.0 MPa | DN300 | 2500 | 600 | 650
KGY-500N | 510 Nm³/min | 0.2–1.0 MPa | DN350 | 2500 | 600 | 750

Technical Characteristics

• Series: KGY series
• Filter media: ultrafine glass fiber with cyclone separation, pre-filtration and coalescing fine filtration stages
• Available connections: threaded (ZG) and flanged (DN) depending on model
• Designed for installation on oil-lubricated compressor outlets to protect downstream equipment and processes
