Condensate collection vessel KFS series

Product Overview
KFS tanks provide a central collection point for condensate and waste oil discharged from compressed-air treatment equipment. Four standard capacities are available: 0.3, 0.5, 1 and 2 m³. Connection sizes, external dimensions and weights are specified per model. Materials, capacity, pressure rating and connections must be confirmed against the process conditions for each application.

Product Features

• Standard models cover capacities from 0.3 to 2 m³.
• Vent, wastewater inlet, overflow, oil drain, drain and discharge connections are provided and specified per model.
• Compact vertical design with model-specific heights and diameters to simplify plant layout.
• Weights and connection sizes listed to support installation and piping design.

Product Specifications
Volume range: 0.3–2 m³
Maximum operating pressure: ≤0.3 MPa
Maximum operating temperature: 125 °C

Models & Specifications (table)
Model | Volume (m³) | Operating Pressure (MPa) | Operating Temperature (°C) | Weight (kg) | Vent Connection (a) | Wastewater Inlet (b) | Overflow Connection (c) | Oil Drain Connection (d) | Drain Connection (e) | Discharge Connection (f) | Height A (mm) | Diameter (mm)
KFS-0.3 | 0.3 | ≤0.3 | 125 | 240 | DN65 | ZG1-1/2″ | ZG1-1/2″ | ZG1″ | ZG1-1/2″ | ZG1″ | 2400 | 700
KFS-0.5 | 0.5 | ≤0.3 | 125 | 300 | DN65 | ZG1-1/2″ | ZG1-1/2″ | ZG1″ | ZG1-1/2″ | ZG1″ | 2850 | 800
KFS-1 | 1 | ≤0.3 | 125 | 400 | DN65 | ZG1-1/2″ | ZG1-1/2″ | ZG1″ | ZG1-1/2″ | ZG1″ | 3150 | 1000
KFS-2 | 2 | ≤0.3 | 125 | 550 | DN65 | ZG1-1/2″ | ZG1-1/2″ | ZG1″ | ZG1-1/2″ | ZG1″ | 3700 | 1200

Technical specifications

• Series: KFS series
• Published capacities: 0.3, 0.5, 1 and 2 m³
• Volume range: 0.3–2 m³
• Maximum operating pressure: ≤0.3 MPa
• Maximum operating temperature: 125 °C
• Connections listed per model: Vent, Wastewater inlet, Overflow, Oil drain, Drain, Discharge (see models table for sizes)
• Weight by model: KFS-0.3 = 240 kg; KFS-0.5 = 300 kg; KFS-1 = 400 kg; KFS-2 = 550 kg
• Height and diameter by model: KFS-0.3 = 2400 x 700 mm; KFS-0.5 = 2850 x 800 mm; KFS-1 = 3150 x 1000 mm; KFS-2 = 3700 x 1200 mm
• Application: Centralized collection of condensate and waste oil from compressed-air filtration, cooling and drying equipment
• Materials, capacity, pressure rating and connections should be confirmed against process conditions
