Electric chamfering and deburring machine SGGB1000

stationaryfor aluminumedge

Product overview: The SGGB1000 removes burrs, dross and performs uniform micro-chamfering on laser-cut parts while preserving dimensional accuracy. Designed to minimize material removal, it targets edges only for efficient processing.

Functions: Rapid removal of burrs and dross from laser-cut edges; consistent micro-chamfering without affecting part dimensions; edge-focused processing to retain original surfaces.

Features:

• Through-feed processing: single pass completes deburring and edge micro-chamfering.
• Double abrasive-belt station for slag and flat burr removal + one-belt two-brush-block station for rounding edges.
• Three station groups operable independently to support polishing, deburring and edge rounding workflows.
• Magnetic conveyor bed for stable clamping and conveying of short ferrous parts.
• Intuitive operation with built-in LED illumination for internal process observation.
• Compact footprint and high throughput suited to batch production.

Suitable materials:

• Carbon steel, stainless steel, aluminum and similar metals.
• Particularly suitable for ferrous workpieces from 30 x 30 mm upward.

Standard accessories:

• Wet dust collector

Optional configuration: High-power narrow abrasive belt + single brush-block for high-volume stamped parts and precision laser-cut components (optional for SGGB1000).

Specifications / key data:

• Model: SGGB1000
• Workpiece width: 1000 mm
• Machine opening: 0–80 mm
• Feed speed: 1–5 m/min
• Total weight: 3500 kg
• Processing stations: three groups (independently operable; includes double-belt de-slag/deburring station and brush-block rounding station)
• Conveying: magnetic conveyor bed (for small ferrous parts)
• Materials: carbon steel, stainless steel, aluminum
• Recommended workpiece size: ferrous parts from 30 x 30 mm
• Standard accessory: wet dust collector
