Water filter aquarens
basketwire meshsintered mesh

Water filter - aquarens - Heation AB - basket / wire mesh / sintered mesh
Water filter - aquarens - Heation AB - basket / wire mesh / sintered mesh
Water filter - aquarens - Heation AB - basket / wire mesh / sintered mesh - image - 2
Add to favorites
Compare this product
Go to the Heation AB website for more information

Characteristics

Designed for
water
Filtration element
basket, wire mesh, sintered mesh
Filtration method
pressure
Applications
for the food industry, industrial, process, for aquaculture, for water treatment, fine, for pipes, for HVAC installations, for HVAC, irrigation, coarse pre-filtration, for heating systems, for cooling systems, for refrigeration circuits, for pipelines
Material
stainless steel
Mounting
threaded, flange, skid-mounted, on skid
Cleaning
self-cleaning
Fluid specification
process water, for raw water, for potable water
Other characteristics
in-line, automatic, high-efficiency
Operating pressure

Min.: 0 bar
(0 psi)

Max.: 16 bar
(232.06 psi)

Filtration size

Min.: 10 µm

Max.: 5,000 µm

Flow

Min.: 0 m³/h
(0 ft³/h)

Max.: 260 m³/h
(9,181.813 ft³/h)

Fluid temperature

Min.: 0 °C
(32 °F)

Max.: 80 °C
(176 °F)

Filtration surface

Min.: 1,500 cm²
(232.5 in²)

Max.: 5,400 cm²
(837 in²)

Description

Description
aquarens is an automatic self-cleaning water jet filter in stainless steel, designed to treat fluids containing a medium to high concentration of suspended solids, including colloidal particles. Using high-pressure water jets, the filter cleans the screen rapidly while minimising backwash water consumption. The unit is available in Y and L construction shapes; O shape available on request.

Design data
Max flow rate [m3/h]: 260
Design pressure [bar]: PN10 (PN16 available on request)
Max temperature [°C]: 80
Salinity [TDS]: <10,000 ppm
pH range: 3 - 9
Design code: PED 68/2014/EU

Material
Filter housing: Stainless steel AISI 304 / AISI 316
Gasket: EPDM*
Drain valve: Nickel-plated brass / AISI 316
Pressure gauges: Stainless steel AISI 304 / AISI 316
Surface finish: Micro shot peening and passivation

Notes
Image for illustration purposes only. Datasheet available on request.

Characteristics / Technical specifications
  • Model name: aquarens
  • Manufacturer / Brand: Heation
  • Type: Automatic self-cleaning water jet filter
  • Suitable for fluids with medium-high suspended solids, including colloidal solids
  • Cleaning method: High-pressure water jets for fast screen cleaning with reduced water consumption
  • Construction shapes: Y and L standard; O available on request
  • Max flow rate: 260 m3/h
  • Design pressure: PN10 (PN16 available on request)
  • Max operating temperature: 80 °C
  • Salinity (TDS): <10,000 ppm
  • pH operating range: 3 – 9
  • Design code: PED 68/2014/EU
  • Filter housing material: Stainless steel AISI 304 / AISI 316
  • Gasket material: EPDM (certified for certain European drinking water regulations)
  • Drain valve: Nickel-plated brass or AISI 316
  • Pressure gauges: Stainless steel AISI 304 / AISI 316
  • Surface finish: Micro shot peening and passivation
  • Certifications: EPDM certified for European drinking water regulations (UBA, DVGW W-270, WRAS, ACS)
