Cube ice maker LIB series

Overview
The solar ice block machine is designed for businesses that need a reliable ice supply while reducing electricity costs and dependence on unstable power grids. By integrating solar photovoltaic (PV) systems with industrial refrigeration technology, this solution enables ice block production using renewable energy, suitable for remote areas, fisheries, islands, and regions with high electricity costs.

System components

• Industrial ice block refrigeration system
• Solar panel power generation system
• Battery energy storage system (optional or hybrid use)
• Intelligent power management control system

Solar Industrial Ice Block Machine (summary)
A solar industrial ice block machine is a standard ice block production system powered partially or fully by solar energy. It ensures continuous ice production even in areas with limited or unstable grid electricity.

How it works

• Solar Power Generation: Solar panels convert sunlight into DC electricity during the daytime.
• Energy Conversion & Storage: An inverter converts DC to AC power; batteries store excess energy for nighttime use.
• Ice Block Production System: The refrigeration compressor uses solar-generated electricity to freeze water in ice molds.
• Smart Power Switching: When solar energy is insufficient, the system automatically switches to grid power or a generator backup (if installed) to ensure continuous operation.

Key benefits of solar integration

• Reduce electricity cost by 40%–90%
• Operate in off-grid or weak-grid areas
• Stable ice production during power outages
• Lower long-term operating expenses
• Environmentally friendly production

Features

• High-Efficiency Solar Integration: MPPT controllers and optimized power matching to maximize solar utilization.
• Industrial Ice Block Production: Produces large ice blocks (5kg–100kg) for fisheries, logistics, and industrial cooling.
• Hybrid Energy System: Supports solar + grid + diesel generator backup for continuous operation.
• Smart Control System: PLC-based control automatically manages energy distribution and freezing cycles.
• Durable Industrial Design: Built with corrosion-resistant steel, suitable for harsh coastal and high-humidity environments.

System configuration options

• Industrial ice block machine unit
• Solar PV panels (monocrystalline recommended)
• Inverter system
• Lithium or gel battery storage system
• Mounting structure for solar panels
• Electrical control cabinet

Optional

• Diesel generator backup
• Remote monitoring system
• Automated ice unloading system

Technical Specifications (table)
Model | Daily Ice Production | Ice Weight | Operating Power | Install Power | Operating Weight | Dimensions (mm)
LIB-10D | 1Ton/24hr | 10kg | 7kw | 10kw | 450kg | 1500x1100x1800
LIB-20D | 2Ton/24hr | 20kg | 14kw | 20kw | 800kg | 2400x1400x2200
LIB-30D | 3Ton/24hr | 20kg | 17.5kw | 25kw | 1450kg | 2400x2200x2200
LIB-50D | 5Ton/24hr | 50kg | 23kw | 30kw | Ice Machine: 3800kg; Cooling Tower: 100kg | Ice Machine: 4800x1800x2200; Cooling Tower: Ø 1430×2290
LIB-100D | 10Ton/24hr | 50kg | 38kw | 50kw | Ice Machine: 4950kg; Cooling Tower: 190kg | Ice Machine: 7000x2200x2550; Cooling Tower: Ø 1620×2360
LIB-150D | 15Ton/24hr | 50kg | 55kw | 75kw | Ice Machine: 7250kg; Cooling Tower: 250kg | Ice Machine: 10000x2200x2550; Cooling Tower: Ø 2000×2595
LIB-200D | 20Ton/24hr | 50kg | 73kw | 100kw | Ice Machine: 8670kg; Cooling Tower: 400kg | Ice Machine: 11800x2200x2550; Cooling Tower: Ø 2180×2690
LIB-250D | 25Ton/24hr | 50kg | 85kw | 120kw | Ice Machine: 11500kg; Cooling Tower: 600kg | Ice Machine: 11850x2912x2550; Cooling Tower: Ø 2180×2790
LIB-300D | 30Ton/24hr | 50kg | 103kw | 150kw | Compressor unit: 150kg; Evaporator: 11000kg; Cooling Tower: 800kg | Compressor unit: 2700x2000x2550; Evaporator: 11800x3102x2550; Cooling Tower: Ø 2750×2850

Technical specifications

• LIB-10D — 1 Ton / 24 hr; ice block 10 kg; operating power 7 kW; install power 10 kW; dimensions 1500x1100x1800 mm; weight 450 kg.
• LIB-20D — 2 Ton / 24 hr; ice block 20 kg; operating power 14 kW; install power 20 kW; dimensions 2400x1400x2200 mm; weight 800 kg.
• LIB-30D — 3 Ton / 24 hr; ice block 20 kg; operating power 17.5 kW; install power 25 kW; dimensions 2400x2200x2200 mm; weight 1450 kg.
• LIB-50D — 5 Ton / 24 hr; ice block 50 kg; operating power 23 kW; install power 30 kW; ice machine weight 3800 kg; cooling tower 100 kg; dimensions (ice machine) 4800x1800x2200 mm.
• LIB-100D — 10 Ton / 24 hr; ice block 50 kg; operating power 38 kW; install power 50 kW; ice machine weight 4950 kg; cooling tower 190 kg; dimensions (ice machine) 7000x2200x2550 mm.
• LIB-150D — 15 Ton / 24 hr; ice block 50 kg; operating power 55 kW; install power 75 kW; ice machine weight 7250 kg; cooling tower 250 kg; dimensions (ice machine) 10000x2200x2550 mm.
• LIB-200D — 20 Ton / 24 hr; ice block 50 kg; operating power 73 kW; install power 100 kW; ice machine weight 8670 kg; cooling tower 400 kg; dimensions (ice machine) 11800x2200x2550 mm.
• LIB-250D — 25 Ton / 24 hr; ice block 50 kg; operating power 85 kW; install power 120 kW; ice machine weight 11500 kg; cooling tower 600 kg; dimensions (ice machine) 11850x2912x2550 mm.
• LIB-300D — 30 Ton / 24 hr; ice block 50 kg; operating power 103 kW; install power 150 kW; compressor unit 150 kg; evaporator 11000 kg; cooling tower 800 kg; dimensions summarized in table above.
