Wall-mounted electrical enclosure KV 9230
DIN railpolystyrenepower distribution

wall-mounted electrical enclosure
wall-mounted electrical enclosure
Add to favorites
Compare this product


Characteristics

Configuration
wall-mounted, DIN rail
Material
polystyrene
Application
power distribution
Width

403 mm
(15.9 in)

Height

483 mm
(19 in)

Depth

129 mm
(5.1 in)

Description

Without terminals For installation of units up to In = 63 A for mounting on DIN rail, top hat profile 35 mm With 1x 18 modules (18 mm) With continuous DIN rail for mounting terminal blocks or operator-independent devices with high space requirements. Type of cover: Door Transparent cover: Yes Width in modules: 18 modules Number of rows: 1 Delivered accessories: Sealing plug, DIN rail(s), blanking strips, labelling strips, cable entry cover IP degree of protection: IP65 DIN rail spacing: 150 mm Cover cutouts: Open With additional space for electrical devices not to be manually actuated: Yes During installation, the climatic effects on the installed equipment must be taken into account, for example high and low ambient temperatures and solar radiation. To reduce the formation of condensed water, see technical information: Formation of condensed water and retaliatory actions. Application area: Indoor installation Maximum ambient temperature 24 h: 35 °C Ambient temperature: -5 °C up to +40 °C Relative humidity: ≤ 50 % at 40 °C, ≤ 100 % at 25 °C Material: Polystyrene Glow wire test according to IEC 60695-2-11: 750 °C UL 94: V-2 Temperature resistance: -25 °C up to +80 °C Halogen-free: Yes Silicone-free: Yes Colour: Grey, similar to RAL 7035 conforming to the standards: EN 60670-1, DIN EN 60670-24
