pulse voltage generator / high-voltage / for EMI/EMC testing
PG 6-364

{{requestButtons}}

Characteristics

  • Type:

    pulse voltage

  • Other characteristics:

    high-voltage

  • Applications:

    for EMI/EMC testing

Description

The high-voltage impulse generator PG 6-364 generates standard impulse voltages with waveforms 1.2/50 μs and 10/700 μs. Output voltage is adjustable between 0.2 kV and 6 kV. The polarity of the output voltage is selectable. Positive, negative or alternating polarity of the output voltage can be preselected.
The generator is designed for dielectric testing of components and systems as well as testing of the electromagnetic compatibility of electronic systems and devices acc. to CCITT K17/K20/K22, ITU-T/K44, IEC 61000-4-5, VDE 0847.
