Digital megohmmeter SM7 series

bench-top

SUPER MEGOHM METER SM7110 Rapid 6.4ms Super Megohm and Low Current Testing Overview The Hioki SM Series Super Megohm Meters are high resistance and ultra low current inspection devices with a 0.1 fA resolution to offer precise testing on production lines. The SM7110 is designed for use in evaluating and testing the performance of electronic components used in products such as smartphones and hybrid vehicles, and supports measurement voltage output of up to 1000 V. Key Features • - 300 times better noise resistance • - Max. 1000 V output : SM7110 • - Max. 2 × 10^19 Ω display • - Min. 0.1 fA resolution • - Built-in EXT I/O, RS-232C, GP-IB and USB • - Flexible, Multipurpose Design, High Resistance Meter/Electrometer/Picoammeter/IR Meter • - Measure resistance of materials by combining with optional electrode Flexible, Multipurpose Design SUPER MEGOHM METER Includes all the following functions: • Electrometer • Picoammeter • IR Meter 1000V / 1*10^19 Ω　Display Perfect for EVs and other high-voltage applications Improved high voltage resistance and isolation performance in components are essential to meet the demands for high efficiency in recent years for applications such as automotive parts and wearable devices.
