Ball screw linear axis HT-S series

with servo-motorprecisionaluminum

Linear axes and axis systems are used in many ranges of industry to transport or position components. HIWIN offers linear axes with toothed belt drive for applications with high dynamics and speed. Thanks to HIWIN's modular system, the belt axes can be bendably combined into double axes and multi-axis systems depending on requirements. HIWIN linear axes with ballscrews are available for applications that require high feed forces and precision. HIWIN linear axes with linear motor drive fulfil the highest requirements in terms of dynamics, precision and synchronisation. HIWIN linear axes with ballscrews are particularly suitable for applications with increased accuracy requirements. Thanks to a freely selectable stroke in millimetre steps and a wide range of options, the axes can be individually adapted to the respective application requirements. The linear tables with ballscrew are flexible positioning modules with integrated double guides. They are ideal in particular for applications requiring heavy loads to be moved with high precision.
