Wheeled loader HL965

for constructionmining and quarryinghandling

Overview
The Hyundai HL965 is a heavy-duty wheel loader engineered for bulk handling, truck-loading and high-volume operations. It is suited to granular materials such as sand and gravel, as well as mining, quarrying and infrastructure projects. The machine combines a durable exterior, strengthened driveline components and operator-focused cabin features to support long operating cycles and simplified maintenance.

Key highlights

• Operating weight: 20,100 kg
• Bucket capacity: 3.60 m³
• Engine: Cummins QSL9 — 201 kW
• Designed for truck-loading and bulk material handling

Technical tables
Engine
Engine model: Cummins QSL9
Engine power: 201 kW

Tipping load
Tipping load: 17,700 kg

Digging force
Breakout force: 17,400 kg

Features & benefits

• Efficient low-speed performance and fuel management: strong low-end torque with ECO Gauge and Eco Pedal to help operators run in economical torque/fuel ranges.
• Sealed driveline centre bearing: robust, sealed support to improve long-term reliability and reduce downtime.
• Spacious ROPS/FOPS cabin: approximately 10% larger cabin with fully adjustable seat options to increase operator ergonomics and reduce fatigue.
• Electro-hydraulic controls: lower operator effort when using attachments, improving cycle times and productivity.
• Hi-MATE telematics available: remote monitoring for maintenance planning and fleet management.
• Fully retractable / tilt-back engine hood: rapid access to engine compartment for cleaning and maintenance; engine room designed to reduce ingress risk.
• Productivity and fuel gains: up to 5% higher productivity in 4th gear and up to 7% improved fuel efficiency in truck-loading cycles.
• Cabin noise reduction: approx. 2 dB lower cabin noise to improve operator comfort during long shifts.
• Engine Auto Shutdown option: reduces idle fuel use and emissions.
• Automatic/manual cumulative weighing system: high-accuracy onboard weighing with two-colour weight indicator and error icons for production control.
• Extended initial service interval: oil and filter service interval extended to 250 hours to increase uptime.
• Cabin comfort options: larger seat with headrest, adjustable armrests, integrated attachment control levers; optional air-suspension seat and seat heating.

Technical specifications

• Model: HL965
• Brand: Hyundai
• Operating weight: 20,100 kg
• Bucket capacity: 3.60 m³
• Engine model: Cummins QSL9
• Engine power: 201 kW
• Tipping load: 17,700 kg
• Breakout force: 17,400 kg
• ROPS/FOPS cabin: ~10% larger
• Fuel-saving systems: ECO Gauge, Eco Pedal, Engine Auto Shutdown (option)
• Telematics: Hi-MATE available
• Maintenance: fully retractable/tilt-back engine hood; initial oil/filter interval 250 hours
• Onboard systems: automatic/manual cumulative weighing system (high accuracy)
