Electric forklift truck 25B-9U

ride-on4-wheelcounterbalanced

Overview
The 80V Hyundai 9‑Series is a 4‑wheel electric forklift designed for efficient, low‑effort material handling in industrial and logistics environments. Models in this range (25BH‑9, 30BH‑9, 35BH‑9) combine brushless AC drive technology with operator‑focused ergonomics to reduce downtime and total cost of ownership.

Application and performance
The 9‑Series covers 2.5–3.5 tonne capacities and is engineered to perform in warehouses, distribution centres, manufacturing plants and other demanding operations. Optional ergonomic cabin and fingertip control levers place all functions within easy reach to lower operator fatigue and maintain productivity across long shifts.

Key features

• Dual drive motor system: two separately controlled drive motors prevent wheel spin on surfaces with uneven grip and deliver strong traction.
• Brushless AC motors: enclosed AC drive and pump motors for improved efficiency, longer maintenance intervals and reduced operating costs.
• Ergonomic operator area: easy‑to‑operate levers and pedals, adjustable steering handle, suspension seat and a large multi‑function cluster for comfortable control.
• LCD colour monitor: 4.3" graphic display showing speed, direction, operating hours and load indicator; three performance modes and multilingual support (up to 11 languages).
• Curve Control: automatically limits travel speed by turning radius for smooth, precise cornering.
• Operator Presence Sensing System (OPSS): disables hydraulic lift/tilt and travel when operator is not seated.
• Anti Roll Back System: improves ramp starting and prevents rollback on inclines.

Highlights (summary)
Load capacity: 2500 / 3000 / 3500 kg
Load center distance: 500 mm
Lifting heights: 3000 - 6000 mm
Battery options: 80V/500Ah; 80V/600Ah
Turning radius: 1925 / 2055 / 2145 mm

Additional information
Selectable performance modes, clear load weight display on the monitor and optional fingertip levers help tailor the 9‑Series to specific site requirements. The combination of brushless AC technology and dual drive motors improves energy use and traction, contributing to lower operating costs and greater uptime.

Technical specifications

• Model / series: Hyundai 9‑Series (25BH‑9, 30BH‑9, 35BH‑9)
• Load capacity: 2500 / 3000 / 3500 kg
• Load center distance: 500 mm
• Lifting heights: 3000 - 6000 mm (model dependent)
• Battery options: 80V/500Ah; 80V/600Ah
• Drive system: Dual drive motor system (two separately controlled drive motors)
• Drive motor type: Brushless AC motors (enclosed drive and pump motor with AC technology)
• Operator aids: 4.3" LCD colour monitor with load indicator; 3 performance modes; OPSS
• Safety features: Curve Control, Anti Roll Back System
