Cold thread rolling FDTRM series

industriallarge seriessmall series

Product Overview
The FDTRM flat-die automatic cold thread rolling machines are engineered for economical cold forming of external threads in both small batches and high-volume production. Models FDTRM-1 to FDTRM-7 cover a diameter range from 1/16 in to 1 in and maximum thread lengths up to 4 in depending on model. Typical outputs range from 20 to 80 pieces per minute and power requirements vary between 2 HP and 20 HP by model.

Available Options

• Maximum thread length (user selectable)
• Minimum and maximum workpiece diameter (user selectable)
• Model selection (FDTRM-1 to FDTRM-7)
• Expected price (user input)
• Purchase timing options: Immediately; Within a week; Within 15 days; Within a month; Other; Unknown

Specifications (table)
Model No. | FDTRM-1 | FDTRM-2 | FDTRM-3 | FDTRM-4 | FDTRM-5 | FDTRM-6 | FDTRM-7
Min. Max. Dia Can Be Rolled | 1/16 in x 1/4 in | 1/8 in x 3/8 in | 1/8 in x 1/2 in | 1/4 in x 5/8 in | 1/4 in x 3/4 in | 1/4 in x 7/8 in | 3/8 in x 1 in
Max. Length of Thread | 2 in | 2.5 in | 3 in | 3 in | 4 in | 4 in | 4 in
Dimension of Fixed Die | 3 in x 2 in x 1 in | 5 in x 2.5 in x 1 in | 5 in x 3 in x 1 in | 6 in x 3 in x 1 in | 6 in x 4 in x 1 in | 7 in x 4 in x 1 in | 8 in x 4 in x 1.5 in
Dimension of Moving Die | 4 in x 2 in x 1 in | 6 in x 2.5 in x 1 in | 6 in x 3 in x 1 in | 7 in x 3 in x 1 in | 7 in x 4 in x 1 in | 8 in x 4 in x 1 in | 9 in x 4 in x 1.5 in
Production in Pieces Per Minute | 80 | 60 | 60 | 50 | 30 | 30 | 20
Power Required in HP | 2 | 3 | 5 | 7.5 | 10 | 15 | 20

Tags
Flat die thread rolling machine; Cold thread rolling machine; Automatic cold thread rolling machine manufacturer India; Automatic cold thread rolling machine exporter India; Industrial machinery manufacturer India; Machinery exporter India; India; Ludhiana Punjab India; Flat die thread rolling machine best price India

Features / Technical specifications

• Series: FDTRM series (models FDTRM-1 to FDTRM-7)
• Diameter range (per model): from 1/16 in up to 1 in depending on model
• Maximum thread length: up to 4 in (model dependent)
• Fixed and moving die dimensions provided per model (see specifications above)
• Production rate: 20 to 80 pieces per minute depending on model
• Power requirement: 2 HP up to 20 HP depending on model
• Machine type: Automatic cold thread rolling, flat-die design
