Automatic trimming machine

Product Overview
IMC automatic head trimming machine trims bolt heads to hexagon or square profiles and reduces shank diameter as required. The IMC-HTM/CHM series is fully automatic, designed for high-throughput finishing of bolts and for easy integration into fastener production lines.

Tags

• Bolt Head Trimming Machine
• Fully Automatic Trimming Machine
• Bolt Head Trimming and Shank Reducing Machine
• Industrial machinery Manufacturer in India
• Machinery Exporter in India
• India
• Ludhiana Punjab India

Available Options

• Maximum length required (input)
• Minimum and maximum job diameter (input)
• Model number of interest (input)
• Expected price (input)
• Purchase timeframe:
  • Immediately
  • Within a week
  • Within 15 days
  • Within a month
  • Other
  • Don't know exactly

Specifications

• IMC-HTM-1 — Bolt length: 1/2\" - 1\" — Diameter range: 80-85 — Production per minute: 80 - 90 — Power: 1 x 1440
• IMC-CHM-2.5 — Bolt length: 1/2\" - 2\" — Diameter range: 70-75 — Production per minute: 60 - 80 — Power: 3 x 1440
• IMC-CHM-3 — Bolt length: 3/4\" - 3\" — Diameter range: 60-65 — Production per minute: 50 - 60 — Power: 5 x 1440
• IMC-CHM-4 — Bolt length: 1\" - 4\" — Diameter range: 45-50 — Production per minute: 40 - 45 — Power: 7.5 x 1440
• IMC-CHM-5 — Bolt length: 1.5\" - 5\" — Diameter range: 35-40 — Production per minute: 30 - 35 — Power: 15 x 1440
• IMC-CHM-6 — Bolt length: 2\" - 6\" — Diameter range: 25-30 — Production per minute: 25 - 30 — Power: 20 x 1440

Technical specifications

• Operation: Fully automatic head trimming and shank reducing.
• Function: Trims bolt heads to hexagon or square profiles and reduces shank per customer requirements.
• Suitable for: Finishing operations in bolt and fastener manufacturing lines.
• Production rates (per minute) by model: IMC-HTM-1: 80-85; IMC-CHM-2.5: 70-75; IMC-CHM-3: 60-65; IMC-CHM-4: 45-50; IMC-CHM-5: 35-40; IMC-CHM-6: 25-30.
• Bolt length ranges by model: IMC-HTM-1: 1/2\" - 1\"; IMC-CHM-2.5: 1/2\" - 2\"; IMC-CHM-3: 3/4\" - 3\"; IMC-CHM-4: 1\" - 4\"; IMC-CHM-5: 1.5\" - 5\"; IMC-CHM-6: 2\" - 6\".
• Power requirements by model (H.P x RPM): IMC-HTM-1: 1 x 1440; IMC-CHM-2.5: 3 x 1440; IMC-CHM-3: 5 x 1440; IMC-CHM-4: 7.5 x 1440; IMC-CHM-5: 15 x 1440; IMC-CHM-6: 20 x 1440.
• Video demonstration available (embedded YouTube video).
