Thermal-magnetic residual current circuit breaker B10TCR3N06-30

overcurrentvoltageresidual current

RCBO 3P+N, 5 module, 10kA C curve, 6A, 30mA, Type AC with Flying Earth Lead Specifications • Neutral Position R • Number of Modules 5 • Residual Current Type AC • Short Circuit Capacity 10.00 • Temperature Range °C -25 to 55 °C • Number of Poles 3P+N • Tripping Curve C • Cable sizes (AWG) 2AWG • Cable size (mm²) 35mm The IMO range of miniature circuit breakers have been designed for protection of electrical installations against overload and short circuits and are manufactured in accordance with IEC 60898-1 Technical Data • Handle central-tripping function for circuit fault indicating • New front design; cover and handle in arc shape • Contact position indicating window; transparent cover to carry label • High short circuit capacity • Suitable for terminal and Pin/Fork type busbar connection • Finger protected connection terminals • Handle padlock device Tripping characteristics in accordance with B, C and D type curves • Curve B: 3-5 In • Curve C: 5-10 In • Curve D: 10-20 In
