DM&P Vortex86DX system-on-module SOM200EX43EGNE1Mini PCIeSATADDR2 SDRAM
Add to favorites
Compare this product
Characteristics
- Processor
- DM&P Vortex86DX
- Ports
- USB 2.0, Ethernet, Mini PCIe, SATA, DDR2 SDRAM
- Other characteristics
- fanless, GPIO
- Applications
- industrial
Description
SOM200 Module Vortex86EX 400MHz CPU with 512MB RAM, SATA, Ethernet, 2xUSB, GPIO, PCI-E, -20 to 70C Operating Temperature
CPU
Processor Installed
Vortex86EX
Max CPU frequency
0.4 GHz
Memory
Form-factor
DDR2
Socket Type
Soldered
ECC
No
Default on Board Memory
0.5 GB
Assembly
Fixed on Board
Graphic
Graphic Controller
Integrated in CPU
Controller Type
Integrated with Chipset
Total Ethernet
1
10/100 Mbit/s
1
Extension Slots
Total
1
Additional Functions
Watchdog timer type
Hardware, Software
Dimensions and weight
Width
70 mm
Length
70 mm
Operating Conditions
Operating Temperature
-20..70 °C
Dimensions
Gross Weight
0.1 kg
