LAN device server

RJ45EthernetRJ45

• To broadcast live announcements to passengers via loudspeakers distributed along the train. • To manage the onboard call between driver and passengers who request assistance (by Passenger Emergency Intercoms) or activate an emergency pad (by Passenger Alarm Intercoms). • To manage the on-board call between driver’s cabins. Main Features The Railways on Board Passenger Announcement and Emergency Call System allows: The train emergency call system is crucial for ensuring passenger safety, quickly responding to emergencies, and enhancing service quality. It allows passengers to immediately contact staff in emergencies, ensuring swift issue resolution. This system is an essential part of modern train operations. Technical Specifications I/O - 1 LAN 10/100 connector: M12 D coded, female - 1 Power supply connector: M12 L coded, male, 24Vdc - 1 Female DB9 connector (service) CPU Module - NXP i.MX–8M Mini - RAM 2GB DDR4 – Flash 8GB eMMC - Linux Based OS Power Consumption - 10W max Power Supply - 24 V according to EN50155:2021 Operating Temperature - -25°C to +70°C (EN50155-2021 class OT3 ST1) Standards and norms - EN 50155 Railways Applications – Electronic Equipment Used on Rolling Stock - EN 45545 Railway applications – Fire protection on railway vehicles - CE Certification - RoHS Compliant - REACH Compliant IP Grade - IP65 Dimensions - With connectors: 220 mm (L) x 64.04 mm (A) x 193.16 mm - Without connectors: 220 mm (L) x 64.04 mm (A) x 177.07 mm Features - Asterisk SIP Server preinstalled • Broadcasts live announcements to passengers • Manages emergency and assistance calls between passengers and driver • Handles inter-cabin communication • Complies with EN50155 and EN45545 railway standards • IP65 protection grade • Linux-based OS with Asterisk SIP Server • Operating temperature: -25°C to +70°C • 24V DC power supply • CE, RoHS, REACH certified
