Diesel engine telehandler 533-105

compactmanoeuvrablehigh-performance

Overview
The JCB 533-105 is a construction telescopic handler engineered for versatile on-site material handling, combining lift capacity, reach and compact manoeuvrability.

Engine and emissions
Equipped with a JCB Dieselmax Stage V engine rated at 55 kW. The machine uses a combined DPF/DOC aftertreatment package that meets Stage V limits without DEF injection. Remote DPF monitoring is available via JCB LiveLink.

• 55 kW JCB Dieselmax Stage V engine
• Combined DPF/DOC aftertreatment — no DEF required
• LiveLink-enabled DPF status monitoring

Productivity and hydraulics
Designed for efficient cycle times, the JCB hydraulic system delivers fast lifting, extending and pushing operations. Compact wheelbase and three steering modes improve manoeuvrability on confined sites.

• Class-leading hydraulics for rapid cycle times
• Compact wheelbase and large steering angles
• Three steer modes for site efficiency

Telematics and ownership
JCB LiveLink telematics maximises fleet uptime and supports preventive maintenance through remote monitoring, fuel and hour tracking, and service alerts.

• Real-time machine hours and location
• Fuel consumption and idle-time reporting
• Service and maintenance notifications; DPF regeneration alerts

Operator comfort and safety
Cabin layout and controls prioritise operator visibility and ergonomics. Safety features include load moment indication, accessible cab entry and optional mirror packages.

• Side-access cabin with wide visibility
• Load moment indicator in operator’s field of view
• Battery isolator and VIN-marked glazing for security (where fitted)

Key specifications

• Max lift height: 10.22 m
• Max lift capacity: 3,300 kg
• Engine power: 55 kW
• Max reach: 6.94 m
• Travel speed: 33 km/h
• Operating weight: 8,850 kg
