Wheeled loader 411

articulatedoutdoorfor construction

Description
The JCB 411 is a medium wheel loader designed for high productivity, low operating costs and versatile site applications.

Productive performance

• 123 l/min double gear pump hydraulics for fast cycle times and multifunction capability.
• Variable geometry turbocharger for increased low-speed performance and improved tractive effort.
• JCB EcoMAX engine delivering 81 kW (109 hp) and 516 Nm for strong response at low revs.
• Choice of axle options to suit specific applications.

Quality, reliability and durability

• Manufactured using robot machining, precision paint processes and advanced assembly techniques to reach high quality standards.
• Precision machining ensures tight tolerances and accurate pin and bush locations.
• Solid cast rear counterweight protects rear components including lights and cooling pack; optional guards available for front screen, lights, underbelly and rear grille.

CommandPlus cab

• Redesigned ROPS with A-pillars aligned to the rear of the cab for increased interior space and a panoramic windscreen.
• Two full-colour LCD screens for operating menus; one screen can display an optional rear-view camera.
• All controls are seat-mounted and move with the seat suspension for consistent ergonomics.
• Command Driving Position offers an optimal control layout for a wide range of operator sizes and preferences.

Reduced maintenance and extended service intervals

• Large single-piece bonnet for easy access to the engine compartment and cooling pack.
• Fluid levels (windshield washer, engine oil, coolant) checkable from the cab; routine checks and greasing points accessible at ground level.
• Cab transmits machine condition and sends real-time alerts to aid uptime.
• Dual-circuit hydraulic brakes with oil-immersed multi-disc design for long life and minimal maintenance.

Operator safety

• Optional rear-view camera displayed on the cab monitor for clear rear vision.
• Optional LED work lights for improved visibility in low-light conditions.
• Inclined, evenly spaced steps and well-positioned handholds to maintain three points of contact when accessing the cab.
• Anti-slip walkways and handrails to facilitate safe movement around the machine.

Technical specifications

• Payload: 2,793 kg
• Bucket capacity: 1.4 m³
• Maximum engine power: 81 kW (109 hp)
• Power type: Diesel
• Tipping load (articulated): 5,451 kg
• Operating weight: 8,722 kg
• Engine: JCB EcoMAX, 516 Nm torque
• Hydraulic pump: double gear pump, 123 l/min
• Options: axle choices, protective guards (windscreen, lights, underbelly, rear grille), LED lighting, rear-view camera
