Mobile scissor lift S2646E

wheeledself-propelledelectric

Overview
The JCB S2646E is an outdoor-rated electric scissor lift designed for indoor and outdoor access applications. It combines electric drive characteristics with features that simplify operation, transport and integration into rental fleets.

Key features

• Outdoor-rated with standard non-marking tyres for mixed indoor/outdoor use.
• Control cradle usable on all sides of the platform for convenient operation from basket or ground.
• Waterproof cover on the power-to-platform outlet to protect the supply socket.
• Spring clips allow platform rails to fold down for manoeuvring in confined spaces.
• Easy-to-read charge level indicator for battery status monitoring.

Reliability and rental readiness
Industry-standard components support seamless integration into existing rental fleets. Design elements such as full pivot boss on the scissor pack, reinforced welds and motor protection plates are implemented to reduce downtime. JCB-specific wear solutions—battery and hydraulic door wear pads—support door load when closed to prevent sagging over time.

Technical specifications

• Maximum working height: 9.9 m
• Platform height: 7.9 m
• Load capacity: 450 kg
• Platform occupants: 2 persons
• Outdoor use: Yes
• Operating weight: 2,663 kg

Support and service

• Standard manufacturer warranty: 2 years or 2,000 hours (conditions apply).
• Access to global dealer network, quick-start guides and good spare parts availability.
• Options for finance, technical support and telematics (LiveLink) for remote monitoring and proactive maintenance.
