Waterjet cutting machine JET START 510A5

plasmafor metalsheet metal

The Jet Start 510A5, 5-axis motion system launches you into complex, contoured cutting right from the start. Cut near-net shapes with edges beveled up to 60° with no taper in tough materials like stainless steel, Inconel, and titanium with no heat affected zone. The Jet Start 510A5 package includes a 5-axis abrasive cutting Z carriage, a rugged 5′ x 10′ isolated catcher tank, Jet Edge’s HERO 50 Intensifier Pump with Jet Smart Controls, IGEMS Software, an 800lb solid phase bulk hopper all with installation and training included. • Aquavision Di Controller for Windows 10 • IGEMS Software with Nesting Program Upgrade • Servoed Z Package • Isolated Abrasive Catch Tank with Slat Kit • Full Featured Handheld Pendant • HERO 50 60k psi 50 hp intensifier pump • Remote Pump Start • 800lb Solid Phase Bulk Hopper • Installation and Training included MOTION SYSTEM CONTROLS/ACCURACY • Aquavision DI fully networkable, industrial PC controller • IGEMS CAD/CAM programming software with nesting upgrade • 5-axis cutting head can cut bevels to 60° taper free • Servo driven Z carriage with 12″ (304 mm) vertical travel height • Full visibility and access to machine code • Isolated catch tank for high precision cutting • Full-featured hand-held pendant • Precision ball screws directly coupled to servo motors • ±0.001″ linear positional accuracy over 12″ (304 mm) per axis • ±0.001″ repeatability (bidirectional) • ±0.003″ renishaw ballbar tests of squareness and straightness over 24″ (608 mm)
