External cylindrical grinding machine ZP E/I

internal cylindricalfor gearscolumn type

Overview
The ZP E/I series uses two independent grinding columns with a shared rotary table and common peripheral units. Designed primarily for job shops and small-batch production, the concept reduces floor space and investment compared with two separate machines while allowing rapid changeover between external and internal gear grinding.

Key features

• Rüstfreier Wechsel zwischen Außen- und Innenbearbeitung (no setup required for changeover)
• Two independent grinding columns operating on a common rotary table
• Single peripheral unit (e.g. cooling lubricant system) to reduce cost and footprint
• Available with different rotary tables and column bases within the ZP series

Technical data (ZP E/I 30 / 40 *)
Model designation: ZP E/I 30 / 40 *
Max. tip diameter: 3,000 / 4,000 mm
Max. workpiece length: on request
Max. module: 50 mm
Max. face width: 1,000 (1,500 / 2,000) mm
Swivel range of grinding head: -45° to +120°
* Values refer to external gear grinding. For internal gear grinding, see ZP I model values.

Specifications

• Machine type: Gear profile grinding machine (ZP E/I series)
• Grinding columns: 2 independent columns
• Common rotary table and shared peripheral units
• Suitable for external and, with ZP I values, internal gears
• Application: job shops, small series and prototype production
• Options: different rotary tables and column base variants
