Stone and concrete cutting wheel DMW 130 Wheel 600

for concretecustom-madeengineering

Overview
KEMROC supplies cutter wheels manufactured to order for varying cutting widths and depths within defined technical boundaries. Confirm compatibility with the manufacturer before use on reinforced concrete containing larger diameter rebar to maintain warranty coverage. Cutter wheel weight depends on diameter and width.

Key features

• Custom-made cutter wheels available within technical boundaries
• Engineered for excavator-mounted cutting operations (recommended carrier weights shown in technical data)
• Multiple cutting width options

Technical data (summary)

• Recommended excavator weight: 20 – 40 t
• Rated power: 130 kW (175 hp)
• Cutter depth (A): 600 mm (24 in)
• Cutting width (B): 80 | 130 | 200 mm (3 | 5 | 8 in)
• Cutting wheel diameter (C): 1,610 mm (63 in)
• Recommended rpm: 80 rpm
• Recommended oil flow: 320 l/min (85 gal/min)
• Max. oil flow: 340 l/min (90 gal/min)
• Max. operating pressure: 400 bar
• Torque at 380 bar: 24,500 Nm
• Cutting force at 380 bar: 31 kN
• Max. rock compressive strength: 80 MPa
• Weight of drive unit, approx.: 1,150 kg
• Weight of cutter wheel, approx.: 300 kg (dependent on diameter/width)
• Weight of dipping device, approx.: 55 kg
• Alternate cutting wheel weight entry on site: 800 kg
• Weight per cutting width: 2,305 kg
• Pick box: PH 32 HD Type
• Number of picks: 40 pcs
• Standard pick: 17/75/70/30 Q
• Standard hole pattern: LB30
• Compatible rotation unit (KRM): KRM60

Notes

• Wheel and component weights depend on diameter and width; multiple weight entries on the page refer to different parts or configurations.
• Wheels can be produced to order with different cutting width/depth variants.

Technical specifications

• Recommended excavator weight: 20 – 40 t
• Rated power: 130 kW
• Cutter depth (A): 600 mm
• Cutting width (B): 80 / 130 / 200 mm
• Cutting wheel diameter (C): 1,610 mm
• Recommended rpm: 80 rpm
• Recommended oil flow: 320 l/min
• Max. oil flow: 340 l/min
• Max. operating pressure: 400 bar
• Torque at 380 bar: 24,500 Nm
• Cutting force at 380 bar: 31 kN
• Max. rock compressive strength: 80 MPa
• Drive unit weight (approx.): 1,150 kg
• Cutter wheel weight (approx.): 300 kg (dependent on diameter/width)
• Dipping device weight (approx.): 55 kg
• Pick system: PH 32 HD, 40 picks, standard pick 17/75/70/30 Q
• Standard hole pattern: LB30
• Compatible rotation unit: KRM60
