Industrial gateway KET-GZE-310

EthernetRS-485Modbus TCP/IP

The KET-GZE-310 Gateway offers advanced features and large storage capacity. Built-in 4G/LTE-M modems and Wi-Fi™ support increase the possibilities for an installation in the absence of LAN connectivity (optional). In addition to the ability to send data to external platforms, there is an internal SD memory that stores data for periods longer than three months. The RS485 port operates in both Master and Slave RTU modes. In addition, it incorporates a ModBUS TCP/IP server that allows connection of the X- Monitor network to SCADA systems, PLCs, HMIs, etc. Integration with proprietary data collection systems is made possible by support for sending data to REST / JSON web services and IEC 60870-5-104 protocol. GENERAL SPECIFICATIONS Degree of protection: IP20 Operating Temperature: -20 ÷ +70 °C Storage Temperature: -20 ÷ +85 °C Relative Humidity: MAX 80% non-condensing CONTAINER 106x90x60mm (WxHxD) 6 DIN modules Blend PC/ABS self-extinguishing UL94-VO Removable screw terminals POWER SUPPLY Voltage: 100÷240VAC (50-60Hz) or 12÷24VDC, 12÷20 VAC Consumption: 6W @ 100÷240VAC/6W @ 12÷24V AC/DC DATALOGGER Memory: Flash on internal microSD card up to 128GB not accessible, RAM 1GB DDR3 Capacity: For periods longer than 3 months RS485 Master or slave ModBUS RTU ETHERNET 10/100/1000 Base-T RADIO Protocols: X-Monitor Protocol (X-MP) / IEEE 802.15.4 Frequency: 2.4GHz ISM Band Output power: +3÷+20 dBm Sensitivity: -104 dBm Antenna: RPSMA connector MODEM Protocols: 4G/LTE-M Antenna: SMA connector Mini-SIM WI-FI Protocols: IEEE 802.11b/g/n standards: 64/128-bit WEP, TKIP, AES, WPA, WPA2 Frequency: 2.4GHz ISM band Antenna: RPSMA connector
