Dimensional measurement system TM-X5000

opticalautomaticparts

Silhouette-Based Analysis for Guaranteed Accuracy Fast and accurate inline measurement. Calibrated high-speed measurement Resistant to target misalignment Simple configuration, advanced capability TM-X5000 Series telecentric measurement systems provide fast and accurate measurement by capturing the silhouette of a target. The dual telecentric optical systems provide reliable results inline by delivering focused images over a large depth of field. This design, in combination with the low-distortion lenses and proprietary algorithms, enable accurate measurements anywhere in the field of view, eliminating the need for precise target placement, external lighting, or even on-site calibration. The user-friendly system can be configured in 3 simple steps and includes over 100 tools for measurement and inspection, including: GD&T, master comparison, and defect distance detection. There are 4 models that can be selected based on the requirements of the application from the compact and ultra-high precision model with a diameter of 6mm to the ultra-wide field of view model with a diameter of 120mm. The dual telecentric optical system—with telecentric lenses in the transmitter and receiver—ensures sharp edges without sacrificing accuracy even for misaligned targets. This technology enables stable measurement in a large depth of field (+/- 20 mm +/- 0.79"), providing a robust solution for inline measurement.
