shape measurement surface measuring machine / roughness / for the automotive industry / CNC
shape measurement surface measuring machine
Formline Roundscan

To safeguard the consistently high quality of your workpieces, you require accurate and reliable measuring systems. The Formline Roundscancombines the form and roughness measurement in a single measurement run. You are able to measure ...

See the other products
JENOPTIK | Light & Production | Industrial Metrolo
surface measuring machine for the automotive industry / deformation monitoring / shape measurement
surface measuring machine for the automotive industry
Formline CFM3010

The CFM3010 measuring system reliably determines form and dimensional deviations on crankshafts, gearshafts and camshafts. The fully automatic measuring machine rapidly supplies high-resolution results, whereby the values remain constant ...

See the other products
JENOPTIK | Light & Production | Industrial Metrolo
optical surface measuring machine / shape measurement / for the automotive industry
optical surface measuring machine
Opticline CA series

Jenoptik designed the Opticline CA, AMV, and WMS series optical measuring systems specifically for automation. With intelligent hardware and software interfaces, they can be integrated flexiblyand seamlessly into your automated production ...

See the other products
JENOPTIK | Light & Production | Industrial Metrolo
optical profiler / video / shape measurement / for thickness measurements
optical profiler
Swift PRO Duo

Swift PRO is a powerful yet easy & simple to operate range of non-contact measuring systems. Combining the latest optical and video measurement technologies, the Swift PRO is the right tool for a broad range of applications from electronics ...

optical profilometer / 3D / flatness / roughness
optical profilometer
VR Series

optical profilometer / laser / in-line
optical profilometer
LJ-V7000 series

The LJ-V series Ultra-High Speed In-line Profilometer is one of the fastest profilometer in the world that can measure approximately 64,000 profiles per second. It functions with an easy 3D display, a ...

optical profilometer / non-contact
optical profilometer
BW-series

Nikon’s proprietary scanning-type optical interference measurement technology achieves 1 picometer (pm) height resolution. Nikon offers a variety of optical microscopes as measurement systems to suit a wide range of measurement applications.

profilometer
profilometer
CV-3200/4500 series

The drive speed of this device has been dramatically increased, with 80mm/s for the X1 axis, as well as 30mm/s for the Z2 one. This helps reduce the total measurement time further. Next, the traverse linearity specification is maintained ...

surface measuring machine
surface measuring machine
SURFCOM, CONTOURECORD series

The Surfcom and Countourecord machines from Zeiss are made in the 1500 to 2900 series with one base column for every model. The sensors are the only items that will change. Added sensors may be placed to create a contour measuring system ...

See the other products
Carl Zeiss Industrielle Messtechnik GmbH
surface measuring machine for industrial applications / shape measurement
surface measuring machine for industrial applications
RONDCOM 54/44

RONDCOM 54/44 RONDCOM 54 is a highly accurate form tester that features a wear-free rotary table mounted on air bearings with the accuracy of 20 nm and comes available in two versions SD and a compact DX version. This new design outclasses ...

See the other products
Carl Zeiss Industrielle Messtechnik GmbH
CNC surface measuring machine / shape measurement
CNC surface measuring machine
RONDCOM 55/47

The Rondcom 55 is a form tester that uses an optional roughness measurement device for more work spots and is especially accurate. It has a rotary table for air bearings and is accurate to about 20 nanometers. The alignment process is ...

See the other products
Carl Zeiss Industrielle Messtechnik GmbH
optical profilometer / 3D / interferometric / white light interferometry
optical profilometer
Nexview™ NX2

Nexview™ NX2 3D Optical Surface Profiler Nexview 3D optical surface profiler excels at measuring all surfaces – from super-smooth to very rough, with sub-nanometer precision, independent of field of ...

See the other products
Zygo Corporation
optical profilometer / 3D / white light interferometry / interferometry
optical profilometer
ZeGage™ Pro

ZeGage™ Pro 3D Optical Surface Profiler with Sub-Nanometer Precision The ZeGage Pro optical profiler expands on the capabilities of the ZeGage profiler with higher precision, faster ...

See the other products
Zygo Corporation
optical profilometer / 3D / interferometry / roughness
optical profilometer
NewView™ 9000

NewView™ 9000 3D Optical Surface Profiler The NewView™ 9000 series of 3D optical surface profilers provide powerful versatility in non-contact optical surface profiling. All measurements are nondestructive, ...

See the other products
Zygo Corporation
optical surface measuring machine / for industrial applications
optical surface measuring machine
WMM 65

The WMM 65 optical measuring device can be modularly configured to meet the requirements of internal quality assurance processes. Integration into a production line or a manual QA workstation is no problem at all. The freely configurable ...

3D profilometer / confocal chromatic / interferometric / optical
3D profilometer
TopMap Pro.Surf+

> Combined measurement of surface roughness and form deviation with the all-in-one optical 3D surface metrology Measure surface roughness and form tolerances < The TopMap Pro.Surf+ offers the customized solution for all surface characterization ...

3D profilometer / interferometric / optical / flatness
3D profilometer
TopMap In.Line

> Fast optical surface inspections right in the production line Surface metrology for in-line measurenment Surface metrology for in-line measurenment Measurements within short cycle times thanks to the latest, high-speed sensor technology > ...

optical profilometer / 3D / roughness / industrial
optical profilometer
IF-Profiler

How to measure roughness and surface finish IF-Profiler is a handheld 3D roughness measurement system for high resolution measurement of surface finish. Users measure roughness of flat and curved components with only one system. Measurements ...

non-contact profiler
non-contact profiler
TR Scan

... that are commonly used in the biomedical engineering industry. Additional features of the TR Scan Non-Contact Surface Measuring Systems include extensive measuring speeds, coupled with vertical resolution rates in ...

non-contact profiler
non-contact profiler
TR Scan - 3D Line

TR Scan allows the measuring of the most sensitive surfaces with astounding speed and precision. The TR Scan can evolve over time, through its different technologies. It meets a wide range of applications: • Modular instrument ...

laser profilometer
laser profilometer
Profile360 series

Profile360 is an in-line, real-time measurement system for continuously monitoring key profile dimensions in complex shapes such as rubber, plastic, ceramic, and wood-plastic composite extrusions, roll-formed metal profiles, and profiled ...

surface measuring machine for industrial applications / shape measurement
surface measuring machine for industrial applications
Virtek LaserQC

With quick examination of sheet metal for precision and monitoring quality, Virtek® LaserQC® is a fast inspection unit that utilizes lasers to measure the precision of two-dimensional components to tolerances within 0.05 mm (0.002 ...

laser profilometer / portable / non-contact
laser profilometer
CALIPRI RCx

CALIPRI RC220 is a hand-held profile measuring instrument for high-precision sampling measurement of rolled products. With CALIPRI RC220, the cutting and cooling of samples for the evaluation of the contour is no longer necessary. The ...

3D profiler / laser / for industrial applications / for production lines
3D profiler
OSIRIS Hot / Cold

OSIRIS is a stationary, optical measuring system for inline control of dimensional accuracy and surface quality of long products. With state-of-the-art laser light cutting technology and high scanning rates, the OSIRIS systems offer a ...

3D profilometer / for angle measurement / surface roughness / geometry
3D profilometer
Form Talysurf PGI NOVUS

Form Talysurf® PGI NOVUS is most advanced system for surface finish, contour, 3D and diameter measurement. At the heart of the new Form Talysurf® PGI NOVUS is a ground-breaking dual bias gauge. The NOVUS gauge provides the ...

See the other products
TAYLOR HOBSON
optical profilometer / 3D
optical profilometer
PGI Matrix

The PGI Matrix is the perfect all-around instrument for fully automated 2D and 3D form metrology of optics ranging from small, mobile phone lenses to large astronomy optics. Our productivity tool kit, offers a unique advantage for ...

See the other products
TAYLOR HOBSON
surface measuring machine for industrial applications / shape measurement
surface measuring machine for industrial applications
PGI Optics

Following its first release in 1984, the Form Talysurf quickly became the number one tool for optics manufactures in measuring aspheric form error. Since then, we have installed thousands across the globe becoming a true industry standard. ...

See the other products
TAYLOR HOBSON
laser scanning profilometer / for brake discs
laser scanning profilometer
IKD Series

PDA based handheld instrument is employed for laser scanning and measurement of brake disks wear parameters. The device is supplied with database and software package for disks wear data storage and processing. IKD Series. Model 2018 Measurement ...

optical profiler / mechanical / visual / video
optical profiler
2D Manual series

The 2D Manual ELBO Visual Measurement Machines are avalaible in three versions to cover a wide range of applications. They are high quality, precision and reliable Instruments already produced in thousands of units. The mechanical structure, ...

optical surface measuring machine / automatic
optical surface measuring machine
2D NC series

The NC ELBO Measurement Machines are avalaible in two versions that make possible to cover a wide range of applications. They are high quality, precision and reliable Instruments already produced in thousands of units. The mechanical ...

optical surface measuring machine / CNC
optical surface measuring machine
2D CNC series

The CNC ELBO Measurement Machines cover the High Range of the Product Range. They are avalaible in two versions that make possible to cover a wide range of travel measurements. They are high quality, precision and reliable Instruments ...

video surface measuring machine / for industrial applications / automatic
video surface measuring machine
3DM542 CNC

Product applications: Mainly used for the measurement of geometric size, type and position tolerances of size measurement, curve, profile measurement, engineering design, development, two-dimensional, ratio measurement; through the ...

laser profiler / vibration measurement / for positioning / deformation monitoring
laser profiler
LDE VHS series

Very High Speed The sensors are intended for non-contact measuring and checking of position, displacement, dimensions, surface profile, deformation, vibrations, sorting and sensing of technological objects as well as for measuring ...

optical profiler
optical profiler
OptiMe

OptiMe is a new family of optical measuring systems based on stereo vision and photogrammetry, comprising two high resolution digital cameras, an illuminator or structured light projector and a PC running proprietary software for data ...

3D profiler / optical / infrared / surface roughness
3D profiler
MicroProf® FE

- Fully automated 2D and 3D surface metrology for Front-End applications - Multi-sensor technology, based on the MicroProf® 300 - Specific inline solution - Wafer Handling Module - Equipment Front End Module (EFEM) The ...

See the other products
FRT GmbH
optical profilometer / 3D / roughness / flatness
optical profilometer
MicroProf® TL

- Optical surface metrology at different sample temperatures - Programmable temperature control - From -80° to 400°C - High heating and cooling rate - Temperature stability: < 1°C - Fully automated The ...

See the other products
FRT GmbH
optical profilometer / roughness
optical profilometer
MicroProf® 100

- compact desktop tool - 100 mm x 150 mm measuring range (lateral) - high measuring speed, max. 200 mm/s - manual and automated measurement and evaluation - individually configurable - TTV option for double-sided measurement The ...

See the other products
FRT GmbH
optical profilometer / industrial / compact
optical profilometer
ProfilControl 7 S

The new key technology for surface inspection of simple to highly complex profiles – innovative and revolutionary! This modularly scalable system, featuring specialist sensor technology, compact design and intelligent process control, ...

See the other products
PIXARGUS GmbH
optical profilometer / industrial
optical profilometer
ProfilControl 7 S XL

Surface inspection of unparalleled precision for large profiles made of plastics, rubber or metals. Up to 16 high-performance cameras guarantee 100-percent quality control of large profiles in diameters ranging between 85 and 250 mm ...

See the other products
PIXARGUS GmbH
optical profilometer / industrial / compact / non-contact
optical profilometer
ProfilControl 7 S Tube

The new key technology for surface inspection of tubes, tubing, hoses, pipes and cables – innovative and revolutionary! This modularly scalable system, featuring specialist sensor technology, compact design and intelligent process ...

See the other products
PIXARGUS GmbH
profiler
profiler

The PROFILER is designed to register the internal corkage profile of wine and champagne bottles, and of all bottles having a long neck. The PC displays the internal profile curve and stores the data on exportable formats ...

portable profiler / temperature measurement
portable profiler
PosiTector SPG

The PosiTector SPG Surface Profile Gage measures and records peak to valley surface profile heights. Conforms to ASTM D4417-B, AS 3894.5-C (with optional 30° tip angle), U.S. Navy NSI 009-32, SANS 5772 and others. Simple Fast measurement ...

portable profiler
portable profiler
PosiTector RTR

PosiTector RTR Replica Tape Reader - Digital spring micrometer measures and records peak to valley surface profile height using replica tape. Simple One-handed menu navigation RESET feature instantly restores factory settings Automatically ...

non-contact profiler
non-contact profiler
KOERZIMAT 1.097 MS

Material evaluation based on magnetic properties MS Magnetic values such as weight-specific saturation polarization σs and volume-specific saturation polarization Js correlate with numerous important process parameters and material ...

How to choose this product

profilometer

Traditional profilometers consist of a very fine probe in contact with the surface to be measured. Its tip moves parallel to the surface, along the x and y axes. Irregularities cause the tip to move perpendicular to the surface, in the z axis. Optical versions replace the tip with a non-contact probe.

Applications

These instruments are used in quality control laboratories to provide information on the state of an object's surface. This is important in polishing and stripping operations. They monitor flatness, smoothness, particle size, manufacturing and machining faults of all types of material.

Technologies

There are both contact and non-contact profilometers. In the former, a stylus moves over the surface, providing information on changes in the z axis, perpendicular to the surface. The latter typically use an optical device to obtain a three-dimensional image of the surface. In some, a laser beam sweeps the study area. In others, images taken from different angles can be used to generate a 3D representation of the surface on a computer.

How to choose

Choice will depend on required precision, from several nanometers to several micrometers, and whether the surface under examination is hard or ductile. Other factors include the speed of data acquisition and whether the probe is likely to scratch or deform the surface.

Advantages

Contact profilometer:
- Compatibility with all surfaces
- Not affected by surface optical qualities
- High resolution
- Relatively inexpensive

Optical profilometer:
- No contact
- No surface deterioration
- Fast

Disadvantages

Contact profilometer:
- Slow
- May scratch surface
- Influenced by surface hardness

Optical profilometer:
- Limited operating radius
